NovaStar MCTRL660 PRO User Manual page 39

MCTRL660 PRO Independent Controller
User Manual
GENLOCK LOOP
ETHERNET
USB IN
USB OUT
100 V –240 V AC
Power
Input voltage
Rated power consumption
Operating temperature
Operating humidity
Dimensions
Net weight
Space requirement
Packing
www.novastar.tech
Genlock loop output connector. Up to 8 MCTRL660 PRO units can
be cascaded.
Fast Ethernet port, which connects to PC and supports TCP/IP
Input port for cascading devices, or connecting to PC
Output port for cascading devices. Up to 8 MCTRL660 PRO units
can be cascaded.
100 V–240 V AC
20.0 W
-20° C–60° C
0% RH–90% RH, non-condensing
482.6 mm × 349.0 mm × 50.7 mm
4.6 kg
1U
Carrying case: 550 mm × 440 mm × 175 mm, white cardboard box
Packing box: 530 mm × 140 mm × 410 mm, craft paper box
Accessory box: white cardboard box
1 × MCTRL660 PRO unit
1 × Ethernet cable (1.5 m)
1 × DVI cable (1.5 m, double magnetic ring design, EMC)
1 × USB cable (1.5 m)
1 × HDMI cable (1.5 m)
1 × Power cord
10 Specifications
34
