MCTRL660 PRO Independent Controller
User Manual
8.3.3 Auto Configuration
Note: Each Ethernet port must load only a whole row or column of cabinets.
Figure 8-5 Each Ethernet port loading only one row of cabinets
Figure 8-6 Each Ethernet port loading only one column of cabinets
Figure 8-7 Auto configuration
Step 1 On the home screen, press the knob to enter the menu.
Step 2 Choose Screen Settings > Auto Config to enter its submenu.
Step 3 Enable Auto Config and select a data flow.
www.novastar.tech
8 Menu Operations
17
