12bit
Video sources with different color depths support different input resolutions. For
details, see
Deep Color Loop Mode Adjust
When multiple MCTRL660 PRO units are cascaded, if the color depth of the output
video source on current device does not match the color depth of the video source
inputted from the previous device, you can select this function on the previous device
to adjust the loop output.

System Settings

Figure 8-20 System settings
Factory Reset
Reset the controller to factory settings.
Go Homepage (s)
Set the time of staying on the current screen before going back to the homepage
when no action is performed. The time range is 30s to 3600s.
OLED Brightness
Adjust the brightness of the OLED menu screen on the front panel.
Hardware Version
Check the hardware version of the controller. If a new version is released, you can
update the firmware programs in NovaLCT or SmartLCT.

Communication Settings

Set the communication mode and network parameters of the MCTRL660 PRO.
www.novastar.tech
Input of 12-bit input source reduces the controller's loading
capacity by half. You cannot perform deep color loop mode
adjustment.
3.2 Video Source Features.
