SHAREMIKE: INITIAL SET-UP
1. Ensure the Topcat is on. The blue light
on the speaker panel of the Topcat will
glow.
2. Turn on the Sharemike by pressing
and holding the power button until
the LED lights.
3. Grip the barrel in the center section.
4. While speaking in a normal voice,
increase the volume using the
Activate Volume button or the Media
Connector Microphone Volume knob
until your voice is barely audible.
REMEMBER: This equipment is designed
to supplement and distribute the user's
voice so they are able to speak in a
conversational tone. Having the volume
set too high will result in feedback and
listener fatigue.
OPTIONAL PAGEFIRST KIT
This optional feature for the Topcat Access interfaces with an independent classroom
paging system. When the page is broadcast, all audio from the system is muted, ensuring
important school-wide messages are never missed. Please note that PageFirst is not
compatible with telephone or IP-based paging systems.
How it works:
1. PageFirst sensor clip is hung around
a lead wire attached to the classroom
paging speaker.
2. The clip is hard-wired to the amplifier.
3. As a page is broadcast, the sensor
clip detects the audio signal through
induction and immediately mutes the
amplifier.
4. When the page is over, the audio
from the amplifier returns to normal
volume level.
(For full installation details, refer to the Topcat Installation Guide.)
DC INPUT PAGING
+ -
AUDIO IN REGISTER PROGRAM
24V/2.5A INPUT
19
