MEDIA CONNECTOR CONTROLS
AND CONNECTIONS
POWER
1
2
1. POWER LIGHT: This light will turn blue
when power is on.
2. POWER BUTTON: Press and hold this
pushbutton to turn the system power on or
off.
3. MICROPHONE VOLUME CONTROL:
Controls the volume level of the
microphones.
4. AUDIO IN VOLUME CONTROL: Controls
the volume level of the connected audio
sources.
5. AUDIO OUT VOLUME CONTROL: Adjusts
the audio signal level output through the
ALD audio output connector.
6. AUDIO LINK LIGHT: The green light blinks
when a link is being established. The light is
solid green when the link is established.
7. SYSTEM ID LABEL: On bottom of unit
MICROPHONE
MIN MAX
7
2
3
4
2
AUDIO IN AUDIO OUT
MIN MAX MIN MAX
5
LINK
6
35
