Wireless Microphone System
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Flexmike and is the answer not in the manual?

Questions and answers

Related Manuals for Lightspeed Flexmike

Summary of Contents for Lightspeed Flexmike

  • Page 1 Wireless Microphone System User Manual...

  • Page 2: Table Of Contents

    2B. Connect the power supply 2C. Optional connection to Cat 885 amplifier 4. Audio integration 5. Charging the Flexmike 6. Operating the Flexmike 7. Using Flexmike as wireless audio link Sharemike: controls & connections Sharemike charging Sharemike initial set-up Daily Operation Instructions...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS Read these instructions. 14. Refer all servicing to qualified service personnel. Servicing is Keep these instructions. required when the apparatus has Heed all warnings. been damaged in any way, such as power-supply cord or plug is Follow all instructions. damaged, liquid has been spilled Do not use the apparatus near or objects have fallen into the...

  • Page 4: Overview

    SYSTEM COMPONENTS AND UNPACKING The standard configuration of the Multimike will contain: Multimike and USB Power Supply MICROPHONE AUDIO IN TONE POWER TREBLE BASS Choice of Flexmike and/or Sharemike Microphone Flexmike Cradle Flexmike Charger & Power Classroom Microphone Supply Sharemike Handheld...
  • Page 5 USB-MCB USB Type A-Micro B power cable for Multimike Flexmike pendant-style audio transceiver w/battery pack NH2.4V AA NiMH rechargeable battery pack for Flexmike Flexmike lavaliere cord Sharemike handheld audio transceiver w/battery pack NH2APK AA NiMH rechargeable battery pack for Sharemike...
  • Page 6 OPTIONAL SYSTEM COMPONENTS MICROPHONE AUDIO IN AUDIO OUT LINK POWER Sharemike Mic Stand Media Connector Earset Microphone Lapel Microphone...
  • Page 7 FRONT PANEL CONTROLS & INDICATORS MICROPHONE AUDIO IN TONE POWER TREBLE BASS 1. POWER LIGHT: This light will turn blue when power is on. 2. POWER BUTTON: Press and hold this push button to turn the system power on or off.
  • Page 8 4. BALANCED AUDIO OUTPUT: allows for a Cat 5 cable connection This output sends the audio from to a Lightspeed 885 amplifier. This Multimike to a balanced input on an connection sends audio to the 885 amplifier or mixer. (Recommended and receives DC power.
  • Page 9 • Blue: solid = normal operation; Blue: flashing = linking in progress • Red: solid = muted; Red: flashing = muted while linking in progress MIC 2 STATUS: This light is not used when operating Flexmike with Multimike system. MICROPHONE CONNECTION: Plug in the optional Lightspeed earset Microphone (EMA) or the Lightspeed lapel (LMA) here.
  • Page 10 FLEXMIKE CRADLE CHARGER DC POWER JACK: Connect the 5V/1.0A DC power cord here. OPTIONAL USB CHARGING JACK: Plug the charging cord for the optional Sharemike microphone here.

  • Page 11: Determine Set-Up Location

    SECTION 2: SET-UP & USE 1. DETERMINE SET-UP LOCATION The Multimike is generally located near the amplifier. This minimizes the length of cable runs, reducing cost and labor and minimizing the possibility of unwanted EMI noise in the system. If cable runs longer than 12 feet are required, we recommend using the balanced audio output with balanced audio cable.

  • Page 12: Connect Multimike To Amplifier

    2A. CONNECT MULTIMIKE TO AMPLIFIER STANDARD UNBALANCED CONNECTION 1. Plug one end of the included 3.5mm cable into the AUDIO OUTPUT connection on the Multimike. 2. Plug the other end into a microphone or audio input connection on an amplifier. USB POWER 5V/0.2A REGISTER...

  • Page 13: Connect The Power Supply

    2C. OPTIONAL CONNECTION TO LIGHTSPEED CAT 885 AMPLIFIER If you are connecting into a new or existing Lightspeed Cat 885 amplifier, you can use Cat 5 cabling to integrate the two components (a 2’ cable is included with the system). This connection will send the audio from Multimike to the Cat 885 as well as provide power for the Multimike (no need for an additional AC power connection).

  • Page 14: Audio Integration

    4. AUDIO INTEGRATION Various multimedia audio sources would typically be connected directly into the audio amplifier to then be played through the speakers. However, there is an additional 3.5mm audio input directly on the Multimike. That audio is passed through the Multimike and back out to the amplifier.

  • Page 15: Charging The Flexmike

    Before use, the Flexmike should be charged. It will take 8-9 hours for the Flexmike to obtain a full charge. A fully charged Flexmike will last for up to 8 hours of use. If microphones are used daily, they should be charged each night.

  • Page 16: Operating The Flexmike

    Flexmikes, 5 Sharemikes or a combination of Flexmikes and Sharemikes for a total of 5. Once the Flexmike is charged, follow these steps to set it up for use. 1. Remove the Flexmike from the cradle charger and put it on by connecting the magnetic clasps behind your neck.

  • Page 17: Using Flexmike As Wireless Audio Link

    7. USING FLEXMIKE AS WIRELESS AUDIO LINK The Flexmike includes a 3.5mm audio input jack to connect to an audio source like a laptop or MP3 player. The Flexmike will transmit the audio signal to be played through the system.

  • Page 18: Sharemike: Controls & Connections

    SHAREMIKE: CONTROLS & CONNECTIONS 1. POWER BUTTON 2. MIC 1 LIGHT: This light indicates operation status for Sharemike • Blue: solid = normal operation; blinking - link in process • Red: solid = muted 3. MIC 2 LIGHT: This light indicates battery/charging status for Sharemike •...

  • Page 19: Sharemike Charging

    SHAREMIKE: CHARGING 1. Make sure the charger is plugged 4. Plug the 5V power supply into the into a wall outlet. Connect barrel end power jack on the charging adaptor of the charging cable into the jack and plug power supply into a wall labeled CHARGE on the bottom of the outlet.

  • Page 20: Sharemike Initial Set-Up

    SHAREMIKE: INITIAL SET-UP Up to 5 microphones can be used with a Multimike. This can consist of 5 Flexmikes, 5 Sharemikes or a combination of Flexmikes and Sharemikes for a total of 5. 1. Ensure the Multimike is on. The blue light on the front of the Multimike will glow.

  • Page 21: Daily Operation Instructions

    The microphone will default to the Mute position, the Mute status will turn to red. • If using a Flexmike with your system, place the Flexmike around your neck. • Press the power/mute button on the microphone. The status will turn blue, indicating the microphone is active and ready to use.
  • Page 22 OPTIONAL ACCESSORIES MEDIA CONNECTOR CONTROLS AND CONNECTIONS LINK MICROPHONE AUDIO IN AUDIO OUT POWER NOTE: When using the Media Connector with Multimike, the maximum number of microphones that can be used is four. 1. POWER LIGHT: This light will turn blue when power is on.
  • Page 23 MEDIA CONNECTOR CONTROLS AND CONNECTIONS CONT’D TONE AUDIO OUT AUDIO IN USB POWER REGISTER TREBLE BASS 5V/1.5A USB1 power adaptor and cable 1. TONE CONTROL: Adjusts the audio 4. TWO AUDIO OUTPUTS: 3.5mm stereo tone, adding more bass or treble for a jacks send audio signal to external more rich or crisp sounds.
  • Page 24 USING THE MEDIA CONNECTOR The Media Connector, when paired together with the system, becomes the primary volume control for the microphones and audio sources you’ve connected. 1. Plug the micro USB end of the power cable into the USB port on the back of the Media Connector.

  • Page 25: Maintenance And

    3. Connect the cable of the new battery pack as shown and insert the battery pack into the compartment. 4. Slide the cover back on and snap into place. 5. Insert the Flexmike into the cradle charger to charge the battery pack.
  • Page 26 BATTERY REPLACEMENT, CONT’D Replacement of battery pack in Sharemike. (Part # NH2APK) 1. Slide the battery door open. 2. Carefully remove the battery pack from the Sharemike. 3. Insert the new battery pack into the compartment. Ensure proper polarity is observed. 4.

  • Page 27: Troubleshooting

    • Confirm batteries are charged each night. A blinking red light on the power button indicates a low battery. • Confirm proper batteries are used. The Flexmike requires the Lightspeed NH2.4V rechargeable battery pack. The Sharemike requires the Lightspeed BA-NH2APK rechargeable battery pack.
  • Page 28 • Avoid wearing jewelry that may rub or bump against the microphone. • Mute the Flexmike during private conversations. You can tell the mic is muted when the light turns red. • Recharge microphones each night. When recharged nightly, operating time (actual...

  • Page 29: Warranty, Safety And

    1. Warranty on Access microphones is FIVE (5) YEARS. 2. Warranty on Lightspeed NiMH rechargeable batteries is one (1) year. 3. A prepaid shipping label will be provided by Lightspeed for warranty repairs within the United States. Customers outside the U.S. should refer to the Lightspeed website (www.lightspeed-tek.com) for warranty repair instructions.
  • Page 30 Union Directives: 2014/30/EU Electromagnetic Compatibility (EMC), 2014/35/EU Low Voltage Directive (LVD) and 2014/53/EU Radio Equipment (RED). Lightspeed Technologies launched a formal product recycle program in Europe that complies with the European Union Directive 2012/19/EU on Waste Electrical and Electronic Equipment (“WEEE Directive”).
  • Page 31 Européenne suivantes : 2004/108/ EC Electromagnetic Compatibility (EMC) and 2006/95/EC Low Voltage Directive (LVD). Lightspeed Technologies a lancé un programme de recyclage de produits en Europe conformément à la directive de l’Union Européenne 2002/96/CE relative aux déchets d’équipements électriques et électroniques (directive «...
  • Page 32 20cm between the radiator (Multimike) and any part of your body. For body worn operation, the portable part (Flexmike) has been tested and meets FCC RF exposure guidelines. This device must not be co-located or operating in conjunction with any other antenna or transmitter. The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 33 NOTICE FOR USB NOTE: Lightspeed is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. Such modifications could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 34: Specifications

    Audio Link indicators: 2 indicators for microphone 1 and 2 Device Registration: Push button for Flexmike(s), Sharemike(s), Media Connector Dimensions (W x H x D): 7.6” x 5” x 1.13” (193 x 127 x 29mm) Weight: 9.6 oz.
  • Page 35 SHAREMIKE Description: Handheld audio transceiver Wireless communication: Access Technology (1.9 GHz) Audio distortion: <1% Integrated microphone: Uni-directional dynamic Audio input: 3.5mm Battery power: 2 AA NiMH battery pack Battery life: 8 hours (fully charged) Charging: 5V charging jack Power: On/off button Registration: Push button for registration with Multimike Dimensions (L x W x H):...
  • Page 36 Access to powerful in-the-moment insights to the learning process. Our audio and video solutions improve student engagement, enable teachers to activate small groups, and encourage collaboration. 11509 SW HERMAN ROAD TUALATIN, OREGON 97062 TOLL FREE: 800.732.8999 PHONE: 503.684.5538 FAX: 503.684.3197 LIGHTSPEED-TEK.COM MN0543US01-1...
