Lightspeed REDCAT ACCESS Setup Manual

REDCAT ACCESS PRESENTER SET UP

Remove Camera Mounting Shoe from your camera tripod (not
included). Set up the tripod and adjust the legs so that the tripod is
stable and the Redcat Access, when attached, is approximately 6 - 7"
from the floor.
If not using battery, plug power supply into Redcat access and
wrap the cord through the cable management slots to provide
strain relief. If using battery pack, simply press power button to
power on Redcat Access
L i g h t sp e ed Techn ol og ies
w w w. l i g ht s pe ed -tek .co m / 80 0.732 .899 9 / 503 .684 .55 38
Attach Camera Mounting Shoe to the RCMB
bracket using the mounting hardware.
Insert the bracket/shoe assembly onto the tripod.
Then slide the Redcat Access onto the bracket as
shown.
If desired, remove the table stand feet from the
Redcat Access.
