Lightspeed 955 Access Quick Start Manual

Quick Start Guide
Connect the power supply
CONNECT
to 955 Access and plug the
POWER TO THE
cord into an AC outlet.
955 ACCESS
USING THE FLEXMIKE
Remove microphone
from charger. Press
the mute button to
unmute, hold near
your mouth and
begin speaking.
ALIGN WITH
COLLARBONE
USING THE SHAREMIKE
Remove microphone
from charger and press
the mute button to
begin speaking.
USING A WIRELESS AUDIO LINK
You can connect your 2nd microphone to your computer's USB port to
enable a wireless 2-way audio link.
SEND AUDIO FROM THE COMPUTER to the 955 Access to ensure all
audio from the computer (videos, video conferencing, audiobooks,
music, etc) can be played through the Lightspeed 955 system and
speakers.
SEND AUDIO TO THE COMPUTER from the 955 Access to ensure the
teacher's Flexmike and any student microphones are clearly picked up by
a video conferencing solution.
Instructional Audio System
955 Access will power
on and the power
light will glow.
POWER/MUTE BUTTON
TALK (BLUE)
MUTE (WHITE)
ADJUST
VOLUME
TALK (BLUE)
MUTE (WHITE)
POWER/MUTE
BUTTON
ADJUST
VOLUME
MICROPHONE AUDIO IN TONE AUDIO OUT
POWER
MIN MAX MIN MAX TREBLE BASS MIN
POWER LIGHT
CHARGE MICROPHONES NIGHTLY
Place the microphones into the cradle
charger. The power status light will glow red
when it is charging.
It takes about 5-6 hours to fully charge the
microphone battery.
When charging is complete,
the power status light will
glow green.
Connect the microphone
to your computer using a
USB-C cable. Open your
computer sound settings to
select FlexmikeAudio as the
microphone and speaker.
USB cable sold separately. Lightspeed offers
a USB-A to USB-C cable for sale (part #USBC)
MAX
NORMAL OPERATION
CHARGING IN PROGRESS
CHARGING COMPLETE
POWER STATUS
LIGHT
