Keypad/Display Menu Structure - Daikin MicroTech III DPS Installation And Maintenance Manual

The following is a description of the MicroTech III menu structure . These menus and items can all be displayed with the keypad/
display. Menu items displayed will change based on the selected unit configuration.
Figure 7: Main Menu – Keypad/Display Menu Structure
Main Menu
►
Enter Password
►
Quick Menu
►
View/Set Unit
System Mode= Local
Heat/Cool In= Heat/Cool
CmpIntrLock=
Dehum Status=
►
Commission Unit
►
Manual Control
►
Service Menus
►
Unit Maintenance
►
Unit Configuration
►
Alarm Lists
►
About This Unit
OM 1263 • MICROTECH UNIT CONTROLLER
See page 8 See page 17 — 17
Enter Password
Quick Menu
►
Enter Password *******
System Mode= Local
Heat/Cool In= Heat/Cool
CmpIntrLock=
Dehum Status=________
Clg Capacity= XXX%
OAD/Econ Cap= XXX%
Htg Capacity= XXX%
Reheat Cap= XXX%
SAF Speed= XXX%
RF/EF Cap= XXX%
OA Temp= XXX°F
See page 39
About This Unit
SO_Item= 123456_12345
Unit SN= FBOU123456789
App Version= 2506017xxx
Cf1-15= xxxxxxxxxxxxxxxx
Cf6-29= xxxxxxxxxxxxxxxx
HMI GUID=
xxxxxxxx-xxxx-xxxx-xxxx-
xxxxxxxxxxxx
OBH GUID=
xxxxxxxx-xxxx-xxxx-xxxx-
xxxxxxxxxxxx

Keypad/Display Menu Structure

See page 18 — 21
View/Set Unit
Unit Status/Settings
Temperatures
Flow Status
SAF Spd Control
RF/EF Control
Date/Time/Schedules
For more detail go to:
Figure 8, page 12
10
Keypad/Display Menu Structure
See page 22 — 30
Commission Unit
►
►
Unit Set-Up
►
►
Timer Settings
►
►
SAF Set-Up
►
►
RF/EF Set-Up
►
►
INV Cmp Set-Up
►
►
OA Fan Set-Up
►
Exp Valve Set-Up
►
Defrost Set-Up
►
Alarm/Event Config
For more detail go to:
Figure 5, page 8
