Universal I/O Status Menu

The Universal I/O Status Menu provides diagnostic information
to qualified service personnel. The items listed in this menu
will provide current status information of the Universal inputs
& outputs. If the universal I/O is configured for resistance,
the value will be displayed in 1/10th ohm scale . If the I/O is
configured for mA, the value will be displayed in micro amps
(1 mA = 1000 micro amps). If I/O is configured for voltage, the
value is displayed in 1/1000th volt scale . Example: MCB-X7
(OA Damper analog output) shows a value of 3000, this would
translate into 3 VDC .
Table 24: Universal I/O Status Menu
Item Display Default
Name Setting
MCB X1= —
MCB X2= —
MCB X3= —
MCB X4= —
MCB X5= —
MCB X6= —
MCB X7= —
MCB X8= —
EMD X1= —
EMD X2= —
EMD X3= —
EMD X4= —
EMD X5= —
EMD X6= —
EMD X7= —
EMD X8= —
OM 1263 • MICROTECH UNIT CONTROLLER
Password
Range
Level
0 – 9999999 2
0 – 9999999 2
0 – 9999999 2
0 – 9999999 2
0 – 9999999 2
0 – 9999999 2
0 – 9999999 2
0 – 9999999 2
0 – 9999999 2
0 – 9999999 2
0 – 9999999 2
0 – 9999999 2
0 – 9999999 2
0 – 9999999 2
0 – 9999999 2
0 – 9999999 2

Digital Input Status Menu

The Digital Input Status Menu provides diagnostic information
to qualified service personnel. The items listed in this menu
will provide current status information of the controller's digital
inputs .
Table 25: Digital Input Status Menu
Item Display
Default Setting
Name
MCB DI1= Off
MCB DI2= Off
MCB DI3= Off
MCB DI4= Off
MCB DI5= Off
MCB DI6= Off
EMB DI1= Off
EMB DI1= Off
EMD DI4= Off

Digital Output Status Menu

The Digital Output Status Menu provides diagnostic
information to qualified service personnel. The items listed
in this menu will provide current status information of the
controller's digital outputs .
Table 26: Digital Output Status Menu
Item Display Default
Name Setting
MCB DO1= Off
MCB DO2= Off
MCB DO3= Off
MCB DO4= Off
MCB DO5= Off
MCB DO6= Off
MCB DO7= Off
MCB DO8= Off
MCB DO9= Off
MCB DO10= Off
EMD DO1= Off
EMD DO2= Off
EMD-DO3= Off
EMD-DO4= Off
EMD DO5= Off
EMD DO6= Off
34
Service Menus
Range Password Level
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Password
Range
Level
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
Off/On 2
