Quick Menu - Daikin MicroTech III DPS Installation And Maintenance Manual

Items in the Quick Menu (see
Quick Menu are Read Only if a valid password has not been entered . The following are brief descriptions of the Quick Menu items .
No password is required to view the Quick Menu.
Table 2: Quick Menu
Menu Display Name
System Mode
Heat/Cool In
CmpIntrLock
Dehum Status
Clg Capacity
OAD/Econo Cap
Htg Capacity
Reheat Capacity
SAF Speed
RF/EF Cap
OA Temp
System Mode is an adjustable item that sets the status for
the for the unit to run on local with field inputs are ignored or
remote where operation is based on field inputs
Heat/Cool In is an adjustable item that only applicable
on heatpump units to determine DX cooling or heatpump
operation
CmpInterLock is an adjustable input safety that can be used
to prevent compressor operation based on external system
safeties
Dehum Status is a status only item which indicates the status
of operation of the dehumidifier. The dehumidifier can be active
or inactive .
Clg Capacity is a status only item which indicates the
percentage of the unit maximum cooling capacity currently
operating .
www .DaikinApplied .com
Table 2) contain basic unit operating status and control set point parameters . The items shown in the
Default Setting
Local
Heat/Cool
—
—
—
—
—
—
—
—
—
Range
Local/Remote
Heat/Cool
Open/Closed
Active/Inactive
0 – 100%
0 – 100%
0 – 100%
0 – 100%
0 – 100%
0 – 100%
-50 .0 – 200 .0°F
OAD/Econo Cap is a status only item which indicates the
percentage that the outdoor damper or economizer valve is
currently open .
Htg Capacity is a status only item which indicates the
percentage of the unit maximum heating capacity currently
operating .
Reheat Capacity is a status only item which indicates the
percentage of the unit maximum reheat capacity currently
operating .
SAF Capacity is a status only item which indicates the
capacity of the supply air fan .
RF/EF Capacity is a status only item indicating the capacity of
the return fan/exhaust air fans .
OA Temp is a status only item which displays the current
temperature reading from the unit mounted outdoor air
temperature sensor . This sensor is standard on all units .
17 OM 1263 • MICROTECH UNIT CONTROLLER

Quick Menu

Quick Menu
Password Level
6
6
6
6
None
None
None
None
None
None
None
