System Mode is an adjustable item that sets the status for
the for the unit to run on local with field inputs are ignored or
remote where operation is based on field inputs
Heat/Cool In is an adjustable item that only applicable
on heatpump units to determine DX cooling or heatpump
operation
CmpInterLock is an adjustable input safety that can be used
to prevent compressor operation based on external system
safeties
CmpCapln is the adjustable input for the amount of DX output
desired
SAFSSIn is the adjustable input for the supply fan start/stop
input
SAFCapIn is adjustable input for the supply fan capacity
desired
EAFSSIn is the adjustable input for the exhaust fan start/stop
input
EAFCapIn is the adjustable input for the exhaust fan capacity
desired
RhtVlvIn is the adjustable input for the amount of hot gas
reheat desired
OADCapIn is the adjustable input for the amount open desired
of outdoor air damper
AlarmResetIn the adjustable point from the field that can reset
applicable refrigeration alarms
Dehum Status is a status only item which indicates the status
of operation of the dehumidifier. The dehumidifier can be active
or inactive .
www .DaikinApplied .com
Clg Status is a status only item which indicates whether or not
mechanical cooling is currently allowed . If cooling is disabled,
the reason is indicated .
Htg Status is a status only item which indicates whether or
not heating is currently allowed . If heating is disabled, the
reason is indicated . If the unit is a heat pump, this applies to
compressor heat .
Clg Capacity is a status only item which indicates the
percentage of the unit maximum cooling capacity currently
operating .
Htg Capacity is a status only item which indicates the
percentage of the unit maximum heating capacity currently
operating . If the unit is a heat pump, this applies to the
compressor heat .
Reheat Capacity is a status only item which indicates the
percentage of the unit maximum reheat capacity currently
operating .
SAF Capacity is a status only item which indicates the
capacity of the supply air fan .
RF/EF Capacity is a status only item indicating the capacity of
the return fan/exhaust air fans .
OAD/EconoCap is a status item which indicates the
percentage that the outdoor damper is currently open .
19 OM 1263 • MICROTECH UNIT CONTROLLER
View/Set Menu
