Specifications

9 Specifications
9.1.1 Mains Supply 1x200-240 V AC
Normal overload 150% for 1 minute
Frequency converter
Typical Shaft Output [kW]
Typical Shaft Output [HP]
IP20
Output current
Continuous (1x200-240 V AC) [A]
Intermittent (1x200-240 V AC) [A]
Max. cable size:
2
(mains, motor) [mm /AWG]
Max. input current
Continuous (1x200-240 V) [A]
Intermittent (1x200-240 V) [A]
Max. mains fuses [A]
Environment
Estimated power loss [W],
1)
Best case/Typical
Weight enclosure IP20 [kg]
Efficiency [%],
Best case/Typical 1)
Table 9.1 Mains Supply 1x200-240 V AC
1)
At rated load conditions
9.1.2 Mains Supply 3x200-240 V AC
Normal overload 150% for 1 min
Frequency converter
Typical Shaft Output [kW]
Typical Shaft Output [HP]
IP20
Output current
Continuous (3x200-240 V) [A]
Intermittent (3x200-240 V) [A]
Max. cable size:
2
(mains, motor) [mm /AWG]
Max. input current
Continuous (3x200-240 V) [A]
Intermittent (3x200-240 V) [A]
Max. mains fuses [A]
Environment
Estimated power loss [W]
Best case/Typical 1)
Weight enclosure IP20 [kg]
Efficiency [%]
1)
Best case/Typical
Table 9.2 Mains Supply 3x200-240 V AC
1)
At rated load conditions.
®
VLT Micro Drive FC 51 Design Guide
PK25
0.25
0.33
M1
1.5
2.3
2.4
3.2
14.0/
20.0
1.1
96.4/
94.9
MG02K302 - Rev. 2013-12-03
PK18 PK37 PK75
0.18 0.37 0.75
0.25 0.5 1
M1 M1 M1
1.2 2.2 4.2
1.8 3.3 6.3
4/10
3.3 6.1 11.6
4.5 8.3 15.6
See chapter 6.6.1 Fuses
12.5/ 20.0/ 36.5/
15.5 25.0 44.0
1.1 1.1 1.1
95.6/ 96.5/ 96.6/
94.5 95.6 96.0
PK37 PK75 P1K5
0.37 0.75 1.5
0.5 1 2
M1 M1 M2
2.2 4.2 6.8
3.3 6.3 10.2
4/10
3.5 6.7 10.9
4.6 8.3 14.4
See chapter 6.6.1 Fuses
19.0/ 31.5/ 51.0/
24.0 39.5 57.0
1.1 1.1 1.6
96.7/ 97.1/ 97.4/
95.8 96.3 97.2
P1K5 P2K2
1.5 2.2
2 3
M2 M3
6.8 9.6
10.2 14.4
18.7 26.4
26.4 37.0
61.0/ 81.0/
67.0 85.1
9
1.6 3.0
97.0/ 96.9/
96.7 97.1
P2K2 P3K7
2.2 3.7
3 5
M3 M3
9.6 15.2
14.4 22.8
15.4 24.3
23.4 35.3
72.0/ 115.0/
77.1 122.8
3.0 3.0
97.2/ 97.3/
97.4 97.4
83
