Specifications
Digital inputs (pulse/encoder inputs)
Programmable digital inputs (pulse/encoder)
Terminal number
Logic
Voltage level
Voltage level, logic'0' PNP
Voltage level, logic'1' PNP
Voltage level, logic '0' NPN
Voltage level, logic '1' NPN
Maximum voltage on input
Input resistance, R
i
Max. pulse frequency at terminal 33
Min. pulse frequency at terminal 33
Analog inputs
Number of analog inputs
Terminal number
Voltage mode (Terminal 53)
Current mode (Terminal 53 and 60)
Voltage level
Input resistance, R
i
Max. voltage
Current level
Input resistance, R
i
Max. current
Analog output
Number of programmable analog outputs
Terminal number
Current range at analog output
Max. load to common at analog output
Max. voltage at analog output
Accuracy on analog output
Scan interval
Resolution on analog output
Scan interval
Control card, RS-485 serial communication
Terminal number
Terminal number 61
Control card, 24 V DC output
Terminal number
Max. load (M1 and M2)
Max. load (M3)
Max. load (M4 and M5)
®
VLT Micro Drive FC 51 Design Guide
MG02K302 - Rev. 2013-12-03
5 (1)
18, 19, 27, 29, 33,
PNP or NPN
0-24 V DC
<5 V DC
>10 V DC
>19 V DC
<14 V DC
28 V DC
approx. 4 kΩ
5000 Hz
20 Hz
53, 60
Switch S200=OFF(U)
Switch S200=ON(I)
0-10 V
approx. 10 kΩ
20 V
0/4 to 20 mA (scaleable)
approx. 200 Ω
30 mA
0/4-20 mA
500 Ω
17 V
Max. error: 0.8% of full scale
4 ms
8 bit
4 ms
68 (P,TX+, RX+), 69 (N,TX-, RX-)
Common for terminals 68 and 69
100 mA
50 mA
80 mA
2
9 9
1
42
12
87
