Specifications
9.1.3 Mains Supply 3x380-480 V AC
Normal overload 150% for 1 min
Frequency converter
Typical Shaft Output [kW]
Typical Shaft Output [HP]
IP 20
Output current
Continuous (3x380-440 V) [A]
Intermittent (3x380-440 V) [A]
Continuous (3x440-480 V) [A]
Intermittent (3x440-480 V) [A]
Max. cable size:
(mains, motor) [mm
Max. input current
Continuous (3x380-440 V) [A]
Intermittent (3x380-440 V) [A]
Continuous (3x440-480 V) [A]
Intermittent (3x440-480 V) [A]
Max. mains fuses [A]
Environment
Estimated power loss [W], Best case/
9 9
1)
Typical
Weight enclosure IP20 [kg]
Efficiency [%], Best case/Typical
Table 9.3 Mains Supply 3x380-480 V AC
1)
At rated load conditions.
84
VLT
2 / AWG]
1)
®
Micro Drive FC 51 Design Guide
PK37 PK75
0.37 0.75
0.5 1
Frame Frame
M1 M1
1.2 2.2
1.8 3.3
1.1 2.1
1.7 3.2
1.9 3.5
2.6 4.7
1.7 3.0
2.3 4.0
18.5/ 28.5/
25.5 43.5
1.1 1.1
96.8/ 97.4/
95.5 96.0
MG02K302 - Rev. 2013-12-03
P1K5 P2K2 P3K0
1.5 2.2 3.0
2 3 4
Frame Frame Frame
M2 M2 M3
3.7 5.3 7.2
5.6 8.0 10.8
3.4 4.8 6.3
5.1 7.2 9.5
4/10
5.9 8.5 11.5
8.7 12.6 16.8
5.1 7.3 9.9
7.5 10.8 14.4
See chapter 6.6 Fuses
41.5/ 57.5/ 75.0/
56.5 81.5 101.6
1.6 1.6 3.0
98.0/ 97.9/ 98.0/
97.2 97.1 97.2
P4K0
4.0
5
Frame
M3
9.0
13.7
8.2
12.3
14.4
20.2
12.4
17.5
98.5/
133.5
3.0
98.0/
97.3
