Selection
NOTICE
•
Reduce common mode interferences by
establishing a low impedance current path to
the frequency converter.
•
To ensure optimum EMC performance, use a
De-Coupling plate kit (ordering numbers
132B0106 or 132B0107)
4 4

4.1.18 Dimensions

Frame
w [mm]
d [mm]
h [mm]
h3 [mm]
w1 [mm]
h1 [mm]
w2 [mm]
h2 [mm]
l1 [mm]
l2 [mm]
PE (metric)
Weight [kg]
Table 4.7 Dimension Data
Illustration 4.33 Dimensions
36
®
VLT Micro Drive FC 51 Design Guide
100 +10
0
+20
300
0
h1
l1 h2
h
h3
M1
70
55
190
230
40
213
55
140
45
7.6
M6
2
MG02K302 - Rev. 2013-12-03
For voltage rating, wire size and fuse selection, see the
®
VLT Micro Drive Quick Guide.
M6
7.8
M4(3x)
Ø5.5
Ø11
M2
75
65
210
250
40
233
59
166.5
38.5
8
M6
3
PE
W
M3
90
69
300
340
55.6
323
69
226
68
9.3
M6
5
