Accessories - Advanced Navigation Spatial FOG Reference Manual

7.4

Accessories

Part Number
SF-DU-KIT
8071-4336-78
SF-CABLE-KIT
BF046WS140612-06
G5Ant-53A4T1
57970-10-INT
OBDII-ODOMETER
AD-UNIT
MOUNT-SUCT
Table 7: Accessories part numbers
Description
Spatial FOG Dual
Antenna Upgrade
Kit
Unterminated
Interface Cable
Spatial FOG
Evaluation Cable
Harness
Right Angle SMA
to TNC 4m Cable
Antcom GNSS
Antenna
Trimble Zephyr
GNSS Antenna
OBDII Odometer
Air Data Unit
Suction Cup
Antenna Mount
Spatial FOG Reference Manual
Page 24 of 144
Version 2.3
03/05/2018
Upgrades Spatial FOG to be a dual
antenna system for enhanced heading
See section 10.4.3
Spatial FOG connector with 2 metres of
unterminated cable
See section 8.9
Spatial FOG connector with 2 metres of
cable to industry standard connectors
See section 8.10
Right Angle SMA to TNC connector 4
metre antenna cable
Antcom G5 L1/L2/L5 GNSS antenna with
survey mount
Trimble Zephyr 2 L1/L2/L5 GNSS Antenna
OBDII Odometer Interface
See section 9.8.2
Air data unit provides pitot and static air
data aiding for Spatial FOG in fixed wing
aircraft
Suction cup 5/8" GNSS antenna survey
mount for easy installation of GNSS
antenna on vehicles
