Table 104: GPIO2 functions
13.10.7.3

Auxiliary RS232 Transmit Functions

Value
0
7
12
39
40
41
42
Table 105: Auxiliary RS232 transmit functions
13.10.7.4

Auxiliary RS232 Receive Functions

Value
0
6
8
9
11
19
20
21
22
42
51
Table 106: Auxiliary RS232 receive functions
Description
Inactive
NMEA Output
ANPP Output
TSS1 Output
Simrad 1000 Output
Simrad 3000 Output
Serial Port Passthrough
Description
Inactive
NMEA Input
Novatel GNSS Input
Topcon GNSS Input
ANPP Input
RTCM Diferential GNSS Corrections Input
Trimble GNSS Input
u-blox GNSS Input
Hemisphere GNSS Input
Serial Port Passthrough
Nortek DVL Binary Format Input
