13.10.7.2

GPIO2 Functions

Value
0
1
2
3
4
5
6
8
9
11
14
15
16
17
18
19
20
21
22
27
28
29
30
31
32
33
34
42
43
44
45
46
51
Description
Inactive
1PPS Output
GNSS Fix Output
Odometer Input
Zero Velocity Input
Pitot Tube Input
NMEA Input
Novatel GNSS Input
Topcon GNSS Input
ANPP Input
Disable GNSS
Disable Pressure
Set Zero Orientation Alignment
System State Packet Trigger
Raw Sensors Packet Trigger
RTCM Diferential GNSS Corrections Input
Trimble GNSS Input
u-blox GNSS Input
Hemisphere GNSS Input
Left Wheel Speed Sensor
Right Wheel Speed Sensor
1PPS Input
Wheel Speed Sensor
Wheel Encoder Phase A
Wheel Encoder Phase B
Event 1 Input
Event 2 Input
Serial Port Passthrough
Gimbal Encoder Phase A
Gimbal Encoder Phase B
Odometer Direction, Forward Low
Odometer Direction, Forward High
Nortek DVL Binary Format Input
