6.5

Accessories

Part Number
GC-NMEA2000-CABLE-6M
GC-POE-CABLE-20M
GC-SER-BREAK-20M
GC-SER-CABLE-20M
POE-INJECTOR
CABLE-FTDI
SUPPLY-24V
CAR12VPWR
ILU
Table 7: Accessories part numbers
All manuals and user guides at all-guides.com
Description
6m NMEA 2000 6m NMEA 2000 drop cable
drop cable for Compatible with serial units only (GC-SER-LC
GNSS Compass and GC-SER-HA)
See section 7.8 for full details
IP68 environmentally sealed connector
20m Ethernet 20m CAT5e Ethernet cable with RJ45
cable for GNSS Compatible with Ethernet units only (GC-POE-
Compass LC and GC-POE-HA)
See section 7.9 for full details
IP68 environmentally sealed connector
20m serial 20m cable to DB9 connectors
breakout cable for Compatible with serial units only (GC-SER-LC
GNSS Compass and GC-SER-HA)
See section 7.10 for full details
IP68 environmentally sealed connector
20m serial cable 20m unterminated cable
for GNSS Compatible with serial units only (GC-SER-LC
Compass and GC-SER-HA)
See section 7.11 for full details
IP68 environmentally sealed connector
AC POE Injector 100 to 240 V AC PoE Injector
USB to RS232 / FTDI USB to RS232 / RS422 (selectable) 1
RS422 cable 1 m metre cable
24V DC Power 100-240V AC Mains to 24V DC Power Supply
Supply (DC jack)
Includes 2-pin plug types A/C/G/I
Car cigarette Car cigarette lighter to 2.1 x 5.5mm DC jack
lighter power power supply
supply
Interface and Interface and logging unit provides a
Logging Unit convenient option for logging and applications
that require multiple NMEA outputs
GNSS Compass Reference Manual
Page 16 of 85
Version 1.1
13/01/2021
