8.5

Communication Specifications

Parameter
Interface
Speed
Protocol
Peripheral Interface
GPIO Level
Table 11: Communication specifications
8.6

Hardware Specifications

Parameter
Operating Voltage
Input Protection
Power Consumption
Backup Battery Capacity
Backup Battery Charge Time
Backup Battery Endurance
Operating Temperature
Environmental Sealing
Shock Limit
Dimensions
Weight
Table 12: Hardware specifications
Spatial FOG Reference Manual
Page 28 of 144
Version 2.3
03/05/2018
Value
RS422 (RS232 optional)
4800 to 10M baud
AN Packet Protocol
2x GPIO
1x Auxiliary RS232
1x GNSS corrections RS232
5 V or RS232
Value
9 to 36 V
-40 to 100 V
550 mA @ 12 V (typical)
> 24 hrs
30 mins
> 10 years
-40 °C to 75 °C
IP68
MIL-STD-810G
25 g
90 x 90 x 96 mm
860 grams
