Component Tray {Serial #16301161 - Mec 1330SE Service And Parts Manual

Component Tray {Serial #16301161 ~ }

ITEM PART NO. QTY DESCRIPTION
1 41932
-- 41242
-- 41243
-- 41932
-- 41933
-- 41245
-- 41246
-- 41247
2 50034
3 53054
4 50002
5 41928
6 41329
7 53067
8 41330
9 41331
10 53068
11 53043 15
12 53038 23
13 41332
14 50027
15 41333
16 50591
17 41250
18 53035
19 41334
20 41251
21 53045
22 50000
23 50047
24 41335
25 50028
26 41252
27 53044
28 41575
29 50423
30 41934
31 41065
32 41254
33 50591
34 41255
35 50524
36 50034
37 41337
• as req: as required
1 Hydraulic power unit
1 Valve body
1 0.8kW Motor - To Serial #1631055
1 1.2kW Motor - From Serial #1631056 (Includes coupler)
1 Pump
1 Lift valve solenoid
1 Steer valve solenoid
1 Tank
2 Screw M10×30
2 Spring washer 10
2 Washer 10
1 Lower Controls Assembly (ECU Module)
1 Sleeve pipe
2 Screw SHCS M5×40
2 Battery
1 DC contactor
3 Screw CSCS M5×8
Spring washer 5
Washer 5
1 Cable Track
4 Screw M6×10
1 Mount Bracket
4 Screw M5×20-H
1 Motor Controller/Traction Module
4 Screw M5×16-H
1 Relay
1 Fuse
2 Screw M5×14-H
8 Washer 6
8 Nut M6
2 Lock
8 Screw M6×20-H
1 Emergency down cable assembly
6 Screw M5×10-H
1 Input Socket
2
Screw M4×12-H
1
Battery Box Weldment
1 Power Switch
2 Charger
8
Screw M5×20-H
2 Glide Track
8 Nut M5
2
Screw M10×30
1 Fix Panel
