Page 2-6
Error Code Description
ANALOG SCISSOR ANGLE CHANNEL A: OPEN
149
CIRCUIT OR SHORT TO GND
ANALOG SCISSOR ANGLE CHANNEL A:
150
SHORT CIRCUIT TO PWR
ANALOG SCISSOR ANGLE CHANNEL A:
151
ANGLE VALUE LOWER THAN MIN.
ANALOG SCISSOR ANGLE CHANNEL A:
152
ANGLE VALUE GREATER THAN MAX.
ANALOG SCISSOR ANGLE CHANNEL B: OPEN
153
CIRCUIT OR SHORT TO GND
ANALOG SCISSOR ANGLE CHANNEL B:
154
SHORT CIRCUIT TO PWR
ANALOG SCISSOR ANGLE CHANNEL B:
155
ANGLE VALUE LOWER THAN MIN.
ANALOG SCISSOR ANGLE CHANNEL B:
156
ANGLE VALUE GREATER THAN MAX.
160 PIN01, OUT00 REDUNDANT CHECK FAULT
161 PIN02, OUT01 REDUNDANT CHECK FAULT
162 PIN04, OUT02 REDUNDANT CHECK FAULT
163 PIN05, OUT03 REDUNDANT CHECK FAULT
164 PIN08, OUT04 REDUNDANT CHECK FAULT
165 PIN09, OUT05 REDUNDANT CHECK FAULT
166 PIN11, OUT06 REDUNDANT CHECK FAULT
167 PIN13, OUT07 REDUNDANT CHECK FAULT
168 PIN17, OUT08 REDUNDANT CHECK FAULT
169 PIN18, OUT09 REDUNDANT CHECK FAULT
170 PIN21, OUT10 REDUNDANT CHECK FAULT
PIN22, OUT POWER RELAY REDUNDANT
171
CHECK FAULT
PIN25, OUT BRAKE1 REDUNDANT CHECK
172
FAULT
PIN26, OUT BRAKE2 REDUNDANT CHECK
173
FAULT
201 TM1 ERR PUMP CURRENT SENSOR OFFSET
202 TM1 ERR TRAC1 CURRENT SENSOR OFFSET
203 TM1 ERR TRAC2 CURRENT SENSOR OFFSET
204 TM1 ERR LOAD HW PARAMETER
205 TM1 ERR LOAD PARAMETER
210 TM1 ERR POWER SUPPLY OUT OF LIMIT
