Chassis Assembly
ITEM PART NO. QTY DESCRIPTION
1 53056 10
2 53043 14
3 53038 17
4 41308 1
5 41309 1
6 41310 1
7 50591 2
8 41311 1
9 50524 2
10 41312 1
11 41306 1
12 50031 4
13 53055 4
14 50001 4
15 41193 1
16 53026 13
17 53046 5
18 50000 5
19 41194 1
20 41195 1
21 53065 2
22 41575 1
23 50423 10
24 50034 8
25 50273 8
26 50002 8
27 41313 2
28 41196 2
29 53044 4
30 41219 1
31 41314 1
32 53066 2
33 41197 2
34 53065 4
35 41315 1
36 41199 2
37 41202 4
38 41316 1
39 41198 1
40 41317 1
41 41318 2
• as req: as required
Screw M5×12-H
Spring washer 5
Washer 5
Cover plate
Cover
Beacon
Screw M5×20-H
Cover plate
Nut M5
Cover
Plate
Bolt M8×25
Spring washer 8
Washer 8
Ladder
Screw M6×12-H
Spring washer 6
Washer 6
Support plate
Height sensor potentiometer
Screw SHCS M4×30
Power Plug
Screw, M4 x 12
Screw M10×30
Spring washer 10
Washer 10
Drive wheel assembly
Latch
Screw M5×10
Pot Hole Protection Assembly
Component Tray
Bolt, SHCS M10 x 15
Pothole switch
Screw M4 x 30-H
Switch cover
Thrust Washer
Bearing
Steer linkage Assembly
Switch cover
Chassis weldment
Cover
• INCL: Included with assembly
"1330SE" Parts Section
• NS: Not a Stock item • REF: Reference only
