Mec 1330SE Service And Parts Manual page 72

Component Tray {Serial #16300001 - #16301160}
ITEM PART NO. QTY DESCRIPTION
1 41241
-- 41242
-- 41243
-- 41244
-- 41245
--
-- 41246
--
-- 41247
2 50034
3 53054
4 50002
5 41248
6 41329
7 53067
8 41330
9 41331
10 53068
11 53043 15
12 53038 23
13 41332
14 50027
15 41333
16 50591
17 41250
18 53035
19 41334
20 41251
21 53045
22 50000
23 50047
24 41335
25 50028
26 41252
27 53044
28 41336
29 41065
30 41254
31 50591
32 41255
33 50524
34 50034
35 41337
36 92107
37 94231
38 93099
• as req: as required
1 Hydraulic power unit
1 Valve body
1 Motor
1 Pump
1 Lift valve solenoid
Coil
1 Steer valve solenoid
2 Coil
1 Tank
2 Screw M10×30
2 Spring washer 10
2 Washer 10
1 Lower Controls Assembly
1 Sleeve pipe
2 Screw SHCS M5×40
2 Battery
1 DC contactor
3 Screw CSCS M5×8
Spring washer 5
Washer 5
1 Cable Track
4 Screw M6×10
1 Mount Bracket
4 Screw M5×20-H
1 Motor Controller/Traction Module
4 Screw M5×16-H
1 Relay
1 Fuse
2 Screw M5×14-H
8 Washer 6
8 Nut M6
2 Lock
8 Screw M6×20-H
1 Emergency down cable assembly
6 Screw M5×10-H
1 Component Tray Weldment
1 Power switch
1 Charger
8 Screw M5×20-H
2 Glide track
8 Nut M5
2 Screw M10×30
1 Bracket
2 Fuse Holder
1 Fuse, 2A, FU3 Power to ECU
1 Fuse, 10A, FU2 Power to Relay Common
• INCL: Included with assembly
"1330SE" Parts Section
• NS: Not a Stock item • REF: Reference only
July 2017
Page A-11
