H C
YDRAULIC
NOTE: Always lubricate threads with clean hydraulic fluid prior to installation.
Use the following values to torque hydraulic components when a specific value is not
available. Always check for torque values in the following places before relying on the
Hydraulic Components Torque Table:
• parts drawings and service instructions in this manual.
• packaging and instruction sheets provided with new parts.
• instruction manuals provided by the manufacturer of the component being serviced.
Type: SAE
PORT SERIES
#4
#6
#8
#10
#12
#16 130-140
OMPONENTS
Cartridge Poppet
Ft. Lbs. Nm
N/A N/A
N/A N/A
25-30 31-41
35-40 47-54
85-90 115-122
176-190
"1330SE" Service and Parts Manual
T T
ORQUE ABLE
Fittings
Ft. Lbs. Nm
N/A N/A
10-20 14-27
25-30 34-41
35-40 47-54
85-90 115-122
130-140 176-190
Hoses
In. Lbs. Nm
135-145 15-16
215-245 24-28
430-470 49-53
680-750 77-85
950-1050 107-119
1300-1368 147-155
