Steering Components
ITEM PART NO. QTY DESCRIPTION
1 50049 2
2 50002 2
3 41210 4
4 41221 1
5 41222 2
6 41223 1
7 41321 2
8 41322 4
9 41225 4
10 41226 2
11 41227 1
12 41228 2
13 50003 2
14 41229 2
15 41323 2
16 50321 6
17 53062 6
18 50284 6
19 41230 2
20 50359 8
21 41324 4
22 41322 2
23 41326 2
24 41233 2
25 41234 2
26 50033 12
27 41327 2
28 41236 2
29 41328 2
30 50030 12
31 41238 1
• as req: as required
Nut M10
Washer 10
Bearing
Tie rod
Bearing
Steering cylinder
Pin
Pin 4×32
Bearing
Washer
Left yoke
Wheel
Washer 12
Nut M12 Castle
Cover
Screw M4×10
Spring washer 4
Washer 4
Bearing Cover
Screw M5×16
Bearing
Pin 3.2×28
Key 6×6×40
Wheel shaft
Connection plate
Bolt M10×25
Shim
Nut M16×1.5 Castle
Shaft end cover plate
Screw M8×20
Right yoke
• INCL: Included with assembly
"1330SE" Parts Section
• NS: Not a Stock item • REF: Reference only
July 2017
Page A-7
