Platform Extension Assembly

ITEM PART NO. QTY DESCRIPTION
1 41279
2 41283
3 41281
4 41282
5 50258
6 53035
7 41120
8 50524 12
9 50001 12
10 50018 12
11 41280
12 50016
13 41361
14 50030
15 53055
16 41140
17 41284
18 53045
19 53069
20 41360
21 41141
22 41359
23 41358
24 8908
-- 50191
-- 50238
• as req: as required
1 Platform guardrail
1 Platform guardrail
1 Platform control box
1 Platform control box mount bracket
4 Screw M8×10-H
2 Screw M5×16-H
2 Bumper
Nut, M8
Washer, M8
Bolt, M8 x 80
1 Platform guardrail
8 Screw M8×55
1 Deck Extension Weldment
2 Bolt M8×20
2 Spring washer 8
1 Platform Extension Lock Assembly
2 Slide Pad
8 Screw M5×14-H
8 Screw M6 x 20
2 Roller Mount
2 Roller
2 Bearing
2 Circlip
1 Manual Enclosure
4 Screw, #10-32 x .5
4 Nut, #10-32 Nylock
• INCL: Included with assembly
