Mec 1330SE Service And Parts Manual page 100

Lift Cylinder Assembly
ITEM PART NO. QTY DESCRIPTION
1 41362 1
2 41287 4
3 -- --
4 41289 1
5 41746 1
41929
6 1
7 41290 1
8 50048 2
9 53055 1
10 50001 2
11 41291 1
12 41292 1
13 53044 1
14 41293 1
15 41294 1
16 53063 1
17 41295 1
• as req: as required
Vent
Bearing
--
Valve manifold
Down Valve Cartridge
Down Valve Coil 1330SE
Lift cylinder
Nut M8
Spring washer 8
Washer 8
Support
Support
Bolt M5×10
Guide sleeve
Cap
Screw M4×8
Seal kit
• INCL: Included with assembly
"1330SE" Parts Section
• NS: Not a Stock item • REF: Reference only
July 2017
Page D-3
