Mec 1330SE Service And Parts Manual page 66

Pothole Protection Assembly
ITEM PART NO. QTY DESCRIPTION
1 41203 4
2 41204 2
3 41205 2
4 41206 2
5 41207 1
6 50430 4
7 41208 1
8 41209 4
9 41210 4
10 50002 7
11 50049 4
12 41211 2
13 41212 2
14 41213 2
15 41214 8
16 53049 6
17 50303 4
18 41215 2
19 50303 2
20 41216 2
21 53056 2
22 41217 2
23 41319 1
24 50049 4
25 41320 1
26 41220 1
• as req: as required
Bearing
Actuator Head
Actuator
Adjusting washer
Pothole Guard
Bolt M10×45
Pothole Guard
Pin, Pothole Guard
Bearing
Washer 10
Nut M10
Linkage Stop
Mount, Gas Spring
Bottom linkage
Bearing
Washer 14
Nut M14
Gas spring
Nut M14
Roller Pin
Screw M5×12
Roller
Mid linkage weldment
Nut M10
Mid linkage weldment
Actuator Seat
• INCL: Included with assembly
"1330SE" Parts Section
• NS: Not a Stock item • REF: Reference only
July 2017
Page A-5
