6. Measure the distance between the test line and your machine reference point.
• Result: The machine stops within the specified braking distance. No action required.
• Result: The machine does not stop within the specified braking distance.
NOTE: The brakes must be able to hold the machine on any slope it is able to climb.
7. Replace the brakes and repeat this procedure beginning with step 1.
Maximum Braking Distance
High Speed on paved surface
D
S
R I V E
P E E D
Proper drive functions are essential to safe machine operation. The drive function
should respond quickly and smoothly to operator control. Drive performance should
also be free of hesitation, jerking and unusual noise over the entire proportionally
controlled speed range.
Perform this procedure with the machine on a firm, level surface that is free of
obstructions.
1. Create start and finish lines by marking two lines on the ground 40 ft /12.2 m apart.
2. Turn the key switch to platform control and turn the red Emergency Stop button clock-
wise to the on position at both the ground and platform controls.
3. Lower the platform to the stowed position.
4. Press the drive function select button.
5. Choose a point on the machine; i.e., contact patch of a tire, as a visual reference for
use when crossing the start and finish lines.
6. Bring the machine to top drive speed before reaching the start line. Begin timing
when your reference point on the machine crosses the start line.
7. Continue at full speed and note the time when your reference point on the machine
passes over the finish line. The time should be 9-11sec.
D
S
R I V E
P E E D
Proper drive functions are essential to safe machine operation. The drive function
should respond quickly and smoothly to operator control. Drive performance should
also be free of hesitation, jerking and unusual noise over the entire proportionally
controlled speed range.
Perform this procedure with the machine on a firm, level surface that is free of
obstructions.
1. Create start and finish lines by marking two lines on the ground 40 ft /12.2 m apart.
2. Turn the key switch to platform control and turn the red Emergency Stop button clock-
wise to the on position at both the ground and platform controls.
3. Press the lift function select button.
4. Press and hold the function enable switch on the joystick.
5. Raise the platform approximately 4 ft /1.2 m from the ground.
6. Press the drive function select button.
7. Choose a point on the machine; i.e., contact patch of a tire, as a visual reference for
use when crossing the start and finish lines.
July 2017
Page 1-8
24 in ± 11.8 in
61 cm ±30 cm
- S
T O W E D
- R
A I S E D
"1330SE" Service and Parts Manual
F
I
R E Q U E N T
N S P E C T I O N
C
H E C K L I S T
