Mec Micro19 Operator's Manual

Hide thumbs Also See for Micro19:
Table of Contents

Advertisement

Quick Links

Operator's Manual
Micro19
Art 5525
Serial Number Range 16911000 - Up
Part # 95335
This manual refers to all machines A92.20 and afterwards.
August 2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Micro19 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mec Micro19

Summary of Contents for Mec Micro19

  • Page 1 Operator’s Manual Micro19 Art 5525 Serial Number Range 16911000 - Up Part # 95335 This manual refers to all machines A92.20 and afterwards. August 2021...
  • Page 2 August 2021 Revision History Date Reason for Update July 2021 New Release MEC Aerial Work Platforms 1401 S. Madera Avenue, Kerman, CA 93630 USA Toll Free: 1-877-632-5438 Phone: 1-559-842-1500 Fax: 1-559-842-1520 info@MECawp.com www.MECawp.com Page  Mcro19 - Operator’s Manual...

  • Page 3: Table Of Contents

    August 2021 Table of Contents Section 1 - Introduction . Introducton ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ Section 2 - Safety Safety ������ ������ ������ ������...

  • Page 4: Section 1 - Introduction

    Your MEC Aerial Work Platform has been designed, built, and tested to provide safe, dependable service. Only authorized, trained and qualified personnel shall be allowed to operate or service the machine.

  • Page 5: Section 2 - Safety

    For your safety and the safety of those around you, you must operate your machine as instructed in this manual. MEC designs aerial work platforms to safely and reliably position personnel, along with their necessary tools and materials, at overhead work locations. The owner/user/operator of the machine should not accept responsibility for the operation of the machine unless properly trained.

  • Page 6: Safety Alert Symbols & Fall ProtectOn

    Secton 2 - Safety August 2021 Safety Alert Symbols & Fall Protection MEC manuals and decals use symbols, colors and signal words to help you recognize important safety, operation and maintenance information. RED and the word DANGER – Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

  • Page 7: Section 3 - Specifications

    Secton 3 - Specfcatons August 2021 Specifications Specifications Indoor 24 ft 4 in 7.6 m Working Height* Outdoor 21 ft 6.4 m Indoor 18 ft 4 in 5.6 m Platform Height Outdoor 15 ft 4.6 m Maximum Drive Height 18 ft 4 in 5.6 m Top Guardrail 79 in...

  • Page 8: Section 4 - Hazards

    Secton 4 - Hazards August 2021 Electrocution Hazards Electrocution Hazards ELECTROCUTION HAZARD! THIS MACHINE IS NOT INSULATED! DEATH OR SERIOUS INJURY will result from contact with or inadequate clearance from any electrically charged conductor. You must maintain a CLEARANCE OF AT LEAST 10 FEET (3.05 m) between any part of the machine, or its load, and any electrical line or apparatus carrying over 300 Volts up to 50,000 Volts.

  • Page 9: EnergZed Conductor Contact Hazard

    Secton 4 - Hazards August 2021 Energized Conductor Contact Hazard 5000 V Max. volts Higher voltage 20000 V Min. volts 15000 V 10000 V 5000 V Lower voltage Min. volts (b) Avoid simultaneous contact across (a) Affected area areas of high potential difference CLEARANCES FROM LIVE AERIAL CONDUCTORS Spotter required...
  • Page 10 Secton 4 - Hazards August 2021 When working in the area of energized conductors the user shall direct and the operator shall comply with the requirements to: Stay at least 10 feet away from power lines with any part of their body, conductive object or any part of the MEWP.

  • Page 11: TP-Over Hazards

    NEVER replace any part of the machine with items of different weight or specification. NEVER modify or alter the work platform without written permission from MEC. NEVER place ladders or scaffolds in the platform or against any part of the machine.

  • Page 12: Fall & CollSOn Hazards

    Secton 4 - Hazards August 2021 Fall & Collision Hazards Fall Hazards DO NOT sit, stand or climb on the platform guard rails. Maintain a firm footing on the platform floor at all times. DO NOT exit the platform when elevated. DO NOT climb down from the platform when elevated.

  • Page 13: AddTOnal Safety Hazards

    Secton 4 - Hazards August 2021 Additional Safety Hazards Explosion and Fire Hazards • DO NOT operate the machine in hazardous locations or locations where potentially flammable or explosive gasses or particles may be present. Damaged Machine Hazards • Conduct a thorough pre-start inspection of the machine and test all functions before each work shift to check for damage, malfunction and unauthorized modification.

  • Page 14: Section 5 - Components And Controls

    Secton 5 - Components and Controls August 2021 Component Locations Component Locations 1) Platform Controller 2) Platform Guard Rails 3) Platform Extension Release Pedal 4) Platform Entry Gate 5) Main Platform 6) Lift Cylinder 7) Entry Ladder 8) Drive Wheels 9) Emergency Lowering Knob 10) Ground Control Panel 11) Batteries Charger...

  • Page 15: Platform Controls

    Secton 5 - Components and Controls August 2021 Platform Controls ART_5011 ALWAYS be aware of the machine’s position and of your surroundings before activating any control function. Control Description Squeeze the Function Enable Switch to enable LIFT & DRIVE & STEER functions 1 Function Enable Switch from Control Handle.

  • Page 16: Lower Controls

    Secton 5 - Components and Controls August 2021 Lower Controls ART_5787 ALWAYS be aware of the machine’s position and of your surroundings before activating any control function. Control Description 1 LED Display Indicates the state of battery charge and displays diagnostic codes when necessary. 2 Hour Meter The hour meter displays the number of hours the machine has operated.

  • Page 17: Section 6 - Workplace Inspection

    Secton 6 - Workplace Inspecton August 2021 Workplace Inspection Workplace Inspection DO NOT operate this machine until you have read and understood this manual, have performed the Workplace Inspection, Pre-Start Inspection and Routine Maintenance, and have completed all the test operations detailed in the Operating Instructions section. Inspect the workplace and determine whether the workplace is suitable for safe machine operation.

  • Page 18: Section 7 - Operating Instructions And Function Tests

    Secton 7 - Operatng Instructons and Functon Tests August 2021 Functions Tests Functions Tests DO NOT operate this machine until you have read and understood this manual, have performed the Workplace Inspection, Pre-Start Inspection and Routine Maintenance, and have completed all the test operations detailed in the Operating Instructions section. This section provides instructions and tests for each function of machine operation.
  • Page 19 Secton 7 - Operatng Instructons and Functon Tests August 2021 Functions Test Select a test area that is firm, level and free of obstruction. Be sure the battery pack is connected. Turn the main power switch to ON (pulled out) position. At the Ground Controls Turn the ground red Emergency Stop button clockwise to the on position Pull out the platform red Emergency Stop button to the on position.
  • Page 20 Secton 7 - Operatng Instructons and Functon Tests August 2021 At the Platform Controls Turn the Key Switch to platform control. Test Emergency Stop Push in the platform red Emergency Stop button to the off position. • Result: No functions should operate. Turn the red Emergency Stop button clockwise to the on position.
  • Page 21 Secton 7 - Operatng Instructons and Functon Tests August 2021 control panel. Test Drive and Braking Press and hold the Function Enable Switch on the control handle. Slowly move the control handle in the direction indicated by the blue up arrow on the control panel until the machine begins to move, then return the handle to the center position.

  • Page 22: OperatNg InstructOns

    Secton 7 - Operatng Instructons and Functon Tests August 2021 Operating Instructions Check the area above and around the machine for obstructions and electrical power lines before operating the machine. Emergency Stop Push in the red Main Power/Lower Emergency Stop Switch button to the off position at the ground controls or the platform controls to stop all machine functions.
  • Page 23 Secton 7 - Operatng Instructons and Functon Tests August 2021 Operation from Ground Drive and steer functions are not available from the ground controls. Turn the Key Switch to ground control. Set the red Emergency Stop buttons to the ON position at both the ground and platform controls.
  • Page 24 Secton 7 - Operatng Instructons and Functon Tests August 2021 To Steer Press the drive function select button. Press and hold the Function Enable Switch on the control handle. Turn the steer wheels with the thumb rocker switch located on the top of the control handle.
  • Page 25 Secton 7 - Operatng Instructons and Functon Tests August 2021 To determine the slope grade Measure the slope with a digital inclinometer OR use the following procedure. You will need: • Carpenter’s level • Straight piece of wood, at least 3.3 ft / 1 m long •...
  • Page 26 Secton 7 - Operatng Instructons and Functon Tests August 2021 Maintenance Lock Raise the platform approximately 7.2ft / 2.2m from the ground. Rotate the Maintenance Lock away from the machine and let it hang down. Maintenance Lock Lower the platform until the Maintenance Lock rests securely on the link.
  • Page 27 Secton 7 - Operatng Instructons and Functon Tests August 2021 Shutdown Procedure • When finished with the machine, place the platform in the stowed position. • Park the machine on a level surface. • Turn the Key Switch to the OFF position and remove the key to prevent unauthorized use. •...

  • Page 28: Section 8 - Battery Charging

    Charge the battery in a well-ventilated area. Use proper AC input voltage for charging as indicated on the machine. Use only MEC authorized batteries and chargers. IMPORTANT: Be sure to disconnect the charger from the outlet before attempting to operate the unit.

  • Page 29: Section 9 - Maintenance

    Secton 9 - Mantenance August 2021 Maintenance Maintenance DO NOT operate this machine until you have read and understood this manual, have performed the Workplace Inspection, Pre-Start Inspection and Routine Maintenance, and have completed all the test operations detailed in the Operating Instructions section. The operator must conduct a Pre-Start Inspection of the machine and test all functions before each work shift to check for damage, malfunction and unauthorized modification.
  • Page 30 Secton 9 - Mantenance August 2021 Use only recommended lubricants. Improper lubricants or incompatible lubricants may cause as much damage as no lubrication. Watch for makeshift “fixes” which can jeopardize safety as well as lead to more costly repair. Inspection and maintenance should be performed by qualified personnel familiar with the equipment.

  • Page 31: RoutNe MaNtenance

    Secton 9 - Mantenance August 2021 Routine Maintenance NEVER perform work or inspection on the machine with the platform elevated without first blocking the scissor assembly with the Maintenance Lock. See page 23 for instructions. IMPORTANT: The operator may perform only maintenance items on the Pre-Start Inspection Checklist.

  • Page 32: LubrCatOn

    Secton 9 - Mantenance August 2021 Lubrication Operator may perform routine maintenance only. Lubrication listed as Scheduled Maintenance must be performed by a qualified service technician. FULL Hydraulic Component Unit Tray ART_5000 Item Specification Frequency Mobile Fluid DTE 10, DTE 13 M, or AW32 Routine Maintenance Check hydraulic oil level every week...

  • Page 33: Pre-Start InspectOn ChecklSt

    Secton 9 - Mantenance August 2021 Pre-Start Inspection Checklist The operator must conduct a Pre-Start Inspection of the machine before each work shift. DO NOT use a damaged or malfunctioning machine. Be sure that the operator’s manual are complete, legible and in the storage container located in the platform.

  • Page 34: Frequent InspectOn ChecklSt

    Secton 9 - Mantenance August 2021 Frequent Inspection Checklist This checklist must be used at 3-month intervals or every 150 hours of machine use, whichever occurs first. Failure to do so could result in death or serious injury. Frequent Maintenance Inspections should be conducted by qualified service technicians only. Photocopy this page for reuse.
  • Page 35 Secton 9 - Mantenance August 2021 Maintenance Inspection Report SE & MICRO Series Scissors Fleet Equipment Number Date Inspector Name Inspector Co. Model Number Address Serial Number Hour Meter Signature Machine Owner & address Maintain all service records in accordance with ANSI A92.24-2019 *If an inspection receives an “N”, remove from service.

  • Page 36: Section 10 - Decals

    Secton 10 - Decals August 2021 Decals Decals 25 26 Opposite Side Also *On Water Diverter Plate Page 33 Mcro19 - Operator’s Manual...
  • Page 37 Secton 10 - Decals August 2021 94559 Qty. - 2 94114 Qty. - 2 41638 Qty. - 2 94362 Qty. - 4 95215 Qty. - 1 90732 Qty. - 2 42534 Qty. - 1 43910 Qty. - 1 94659 Qty. - 1 44536 Qty.
  • Page 38 Secton 10 - Decals August 2021 Serial Plate The serial plate is attached to the machine at the time of manufacture. Important information about the machine is recorded on the serial plate. ART_4999 Serial Plate Description MODEL NUMBER: Identifies the machine. MFG DATE: Month / Year of manufacture.

  • Page 39: Section 11 - Troubleshooting

    Hydraulic fluid level low? • Obvious fluid leak or damaged component? • Wires disconnected, broken, or loose? • Diagnostic panel on? • Platform Control Box Fault Code present? Refer to service manual or contact MEC Technical Support. Page 36 Mcro19 - Operator’s Manual...

  • Page 40: Section 12 - Transporting And Lifting Instruction

    MEC machinery. Truck drivers are responsible for loading and securing machines, and should be properly trained and authorized to operate MEC machinery. Drivers are also responsible for selecting the correct and appropriate trailer according to government regulations and company policy. Drivers must ensure that the vehicle and chains are strong enough to hold the weight of the machine (see the serial number plate for machine weight).
  • Page 41 Secton 12 - Transportng and Lftng Instructon August 2021 Resetting Brakes Press the Emergency Stop button, then push the Brake Release Switch to the right to reset the brake. Driving or Winching onto or off of a Transport Vehicle Always attach the machine to a winch when loading or unloading from a truck or trailer by driving.
  • Page 42 Secton 12 - Transportng and Lftng Instructon August 2021 • Use a minimum of four (4) chains or straps. • Adjust the rigging to prevent damage to the chains and the machine. Ensure that angle of each hold-down chain or strap does not exceed 30° relative to the trailer deck.
  • Page 43 August 2021 Notes Page 40 Mcro19 - Operator’s Manual...
  • Page 44 August 2021 Notes Page 41 Mcro19 - Operator’s Manual...
  • Page 45 August 2021 Notes Page 42 Mcro19 - Operator’s Manual...
  • Page 46 MEC Parts Order Form Phone: 559-842-1523 Fax: 559-400-6723 Email: Parts@mecawp.com Please Fill Out Completely: Date: Ordered By: Account: Your Fax No.: Bill to: Ship to: Purchase Order Number Ship VIA ** All orders MUST have a Purchase Order Number **Fed Ex shpments requre Fed Ex account number...
  • Page 47 MEC Aerial Platform Sales Corp. and is found upon inspection by MEC Aerial Platform Sales Corp. to be defective in material and/or workmanship. MEC Aerial Platform Sales Corp. shall not be liable for any consequential, incidental or contingent damages whatsoever.
  • Page 48 MEC Aerial Work Platforms 1401 S. Madera Avenue, Kerman, CA 93630 USA Toll Free: 1-877-632-5438 Phone: 1-559-842-1500 Fax: 1-559-842-1520 info@MECawp.com www.MECawp.com...
