Error Code Description
ANALOG SCISSOR ANGLE REDUNDANT
117
CHECK FAULT
120 KEY SWITCH INPUT CHECK FAULT
121 TOGGLE SWITCH INPUT CHECK FAULT
122 PIN29, INP00 REDUNDANT CHECK FAULT
123 PIN30, INP01 REDUNDANT CHECK FAULT
124 PIN32, INP02 REDUNDANT CHECK FAULT
125 PIN33, INP03 REDUNDANT CHECK FAULT
126 PIN06, INP04 REDUNDANT CHECK FAULT
127 PIN34, INP05 REDUNDANT CHECK FAULT
128 PIN45, INP10 REDUNDANT CHECK FAULT
129 PIN46, INP11 REDUNDANT CHECK FAULT
130 PIN47, INP12 REDUNDANT CHECK FAULT
131 PIN48, INP13 REDUNDANT CHECK FAULT
132 PIN49, INP14 REDUNDANT CHECK FAULT
133 PIN50, INP15 REDUNDANT CHECK FAULT
PIN19, INP RELAY REDUNDANT CHECK
134
FAULT
PIN20, INP BRAKE REDUNDANT CHECK
135
FAULT
136 PIN23, INP M1 REDUNDANT CHECK FAULT
137 PIN24, INP M2 REDUNDANT CHECK FAULT
PRESSURE SENSOR N.1 OPEN CIRCUIT OR
140
SHORT TO GND
PRESSURE SENSOR N.1 SHORT CIRCUIT TO
141
PWR
PRESSURE SENSOR N.1 VALUE LOWER
142
THAN THRESHOLD MIN.
PRESSURE SENSOR N.1 VALUE GREATER
143
THAN THRESHOLD MAX.
PRESSURE SENSOR N.2 OPEN CIRCUIT OR
144
SHORT TO GND
PRESSURE SENSOR N.2 SHORT CIRCUIT TO
145
PWR
PRESSURE SENSOR N.2 VALUE LOWER
146
THAN THRESHOLD MIN.
PRESSURE SENSOR N.2 VALUE GREATER
147
THAN THRESHOLD MAX.
