Machine Specifications - Mec 1330SE Service And Parts Manual

M S
ACHINE PECIFICATIONS
Working Height*
Platform Height
Maximum Drive Height
Stowed Height
Guardrail Height
Toeboard Height
Machine Weight** (Unloaded)
Lift Capacity
Deck Extension Capacity
Maximum Occupants
Length-Stowed (Overall)
Length-Stowed (Ladder Removed)
Platform Length (Extended)
Platform Length (Retracted)
Width (Overall)
Platform Width (Outside)
Wheel Base
Turning Radius--Inside
Ground Clearance--Stowed
Ground Clearance--Elevated
Drive Speed (Proportional)
Gradability
Maximum Side Slope--Stowed
Ground Pressure/Wheel
Maximum Wheel Load
Occupied Floor Pressure
Maximum Operating Wind Speed
Tire Size
Lug Nut Torque
Hydraulic Pressure
Power System Voltage
Battery Charger
Batteries
Meets applicable requirements of ANSI A92.6-2006.
*Working Height adds 6 feet (2 m) to platform height. **Weight may increase with certain options.
*** Uniform Pressure of 1330SE can be reduced to 111.2 (542.93 kg/sq.M) (unloaded) to 142.2 (694.3 kg/sq.M) (loaded)
by extending the slide out platform
July 2017
Page II
Top Guardrail
Platform Floor
Total
Stowed 0-2.5 mph
Raised or extended 0-.7 mph
Input
Output
"1330SE" Service and Parts Manual
1330SE
19 ft 6 m
13 ft 4 m
13 ft 4 m
74 in. 1.9 m
35 in. .9 m
39 in. 1 m
6 in. 15 cm
1900 lb 860 kg
530 lb 240 kg
1 Person / 250lb (113 kg)
2
58 in. 1.5 m
51 in. 1.3 m
75 in. 1.9 m
51 in. 1.3 m
30 in. 76 cm
27.5 in. 70 cm
41 in 1 m
18 in. 45 cm
2.5 in 6 cm
0.6 in 1.5 cm
0-4 km/h
0-1.1 km/h
25%/14°
5°
112 psi
7.9 kg/cm
730 lb 331 kg
234 psf
1138 kg/m
28 mph / 12.5 m/sec (45 km/h)
9 x 3 inch/230 x 80mm
19 ft-lb / 25.5 Nm
Secured with cotter pin
2250 psi/ 155 bar
24 Volt DC
110-230 V AC, 50-60 Hz
24 Volt DC
Two 12-Volt deep cycle; 85Ah
2
2
