Free-Wheel Configuration For Winching Or Towing - Mec 1330SE Service And Parts Manual

F -W
R E E H E E L
RUNAWAY HAZARD!
AFTER RELEASING THE BRAKES THERE IS NOTHING TO STOP MACHINE
TRAVEL. MACHINE WILL ROLL FREELY ON SLOPES.
ALWAYS CHOCK THE WHEELS BEFORE MANUALLY RELEASING THE BRAKES.
The machine can be winched or towed short distances at speeds not to exceed 2.5
MPH (4 km/h). Before towing or winching the machine, it is necessary to release the
brakes. Reset the brakes after towing or winching.
Push Down
& Hold
Turn to
Ground
ART_4998
BE SURE THAT THE BRAKES ARE ENGAGED BEFORE REMOVING THE WHEEL
CHOCKS.
"1330SE" Service and Parts Manual
C
O N F I G U R A T I O N
D B
ISENGAGE RAKES BEFORE
1.Chock the wheels.
2.Turn the Key Switch to the OFF position.
3.Turn the red Emergency Stop button clockwise to the on
position at both the ground and platform controls.
4.At the Ground Controls panel, press and hold the Lift/Lower
Switch to the DOWN position, then turn on the Key Switch to the
"Ground" position.
5.Hold the Lift/Lower Switch in this position until a continuous
alarm sounds, signalling that the brake has been released.
E B
NGAGE RAKES BEFORE
Turn the Key Switch to the OFF position to reset the brake.
F W
O R I N C H I N G O R
T
OWING OR
D
RIVING
T
O W I N G
W
INCHING
July 2017
Page XI
