- Page 1 Operator’s Manual 69 Series ART_4265 RT - Internal Combustion 3369ERT Serial Number Range 13200000 - Up Part # 43443 ERT - Electric 3369RT Serial Number Range 13300000 - Up February 2019 4069ERT Serial Number Range 13700000 - Up 4069RT Serial Number Range 13800000 - Up...
- Page 2 Date Reason for Update February 2019 New Release MEC Aerial Work Platforms 1401 S. Madera Avenue, Kerman, CA 93630 USA Toll Free: 1 - 877 - 632 - 5438 Phone: 1 - 559 - 842 - 1500 Fax: 1 - 559 - 842 - 1520 info@MECawp.com...
-
Page 3: Table Of Contents
February 2019 Table of Contents Section 1 - Introduction ����� ����� ����� ����� ����� ����� ����� ����� ����� ����� ����� ����� ����� ����� ����� ����� Introducton ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ ������ ������... -
Page 4: Section 1 - Introduction
Your MEC Aerial Work Platform has been designed, built, and tested to provide safe, dependable service. Only authorized, trained and qualified personnel shall be allowed to operate or service the machine. -
Page 5: Section 2 - Safety
For your safety and the safety of those around you, you must operate your machine as instructed in this manual. MEC designs aerial work platforms to safely and reliably position personnel, along with their necessary tools and materials, at overhead work locations. The owner/user/operator of the machine should not accept responsibility for the operation of the machine unless properly trained. -
Page 6: Safety Alert Symbols & Fall ProtectOn
Secton 2 - Safety February 2019 Safety Alert Symbols & Fall Protection MEC manuals and decals use symbols, colors and signal words to help you recognize important safety, operation and maintenance information. RED and the word DANGER – Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury�����... -
Page 7: Section 3 - Safety Rules And Hazards
Secton 3 - Safety Rules and Hazards February 2019 Safety Rules Safety Rules Failure to obey the instructions and safety rules in this manual will result in death or serious injury����� Do Not Operate Unless: You learn and practice the principles of safe machine operation contained in this operator’s manual. -
Page 8: Safety And Hazards
Secton 3 - Safety Rules and Hazards February 2019 Safety and Hazards Electrocution Hazards This machine is not electrically insulated and will not provide protection from contact with or proximity to electrical current. Maintain safe distances from electrical power lines and apparatus in accordance with applicable governmental regulations and the following chart. - Page 9 Secton 3 - Safety Rules and Hazards February 2019 Do not depend on the tilt alarm as a level indicator. The tilt alarm sounds on the chassis and in the platform when the machine is on a slope. If the tilt alarm sounds: •...
- Page 10 Secton 3 - Safety Rules and Hazards February 2019 Do not replace items critical to machine stability with items of different weight or specification. Do not modify or alter an aerial work platform without prior written permission from the manufacturer. Do not place ladders or scaffolds in the platform or against any part of this machine.
- Page 11 Secton 3 - Safety Rules and Hazards February 2019 Close the entry gate before operating. Do not operate the machine unless the guard rails are properly installed and the entry is secured for operation. Do not enter or exit the platform unless the machine is in the stowed position. Collision Hazards Be aware of limited sight distance and blind spots when driving or operating.
- Page 12 Secton 3 - Safety Rules and Hazards February 2019 Do not start the engine if you smell or detect liquid petroleum gas (LPG), gasoline, diesel fuel or other explosive substances. Do not refuel the machine with the engine running. Refuel the machine and charge the battery only in an open, well-ventilated area away from sparks, flames and lighted tobacco.
- Page 13 Secton 3 - Safety Rules and Hazards February 2019 Do not raise the platform unless all four outriggers are properly lowered, the footpads are in firm contact with the ground and the machine is level. Do not adjust the outriggers while the platform is raised. Do not drive while the outriggers are lowered.
-
Page 14: Ground Control Panel
Secton 4 - Control Panel February 2019 Ground Control Panel Ground Control Panel Control Description Platform Up Button Press this button and the platform will lift. Display Diagnostic readout Press this button to select the engine idle setting. Light on Engine Idle Select Button indicates high idle is selected. -
Page 15: Platform Control Panel
Secton 4 - Control Panel February 2019 Platform Control Panel Control Function Handle Enable Switch SPEED ART_4729 Control Description Push in the red Emergency Stop button to the off position to stop all functions. Pull out the red Red Emergency Stop Button Emergency Stop button to the on position to operate the machine. - Page 16 Secton 5 - Pre-Operaton & Workplace Inspecton February 2019 Pre-Operation Inspection Pre-Operation Inspection Do Not Operate Unless: • You learn and practice the principles of safe machine operation contained in this operator’s manual. Avoid hazardous situations. 2����� Always perform a pre-operation inspection����� 3�����...
-
Page 17: Pre-OperatOn InspectOn Report
Secton 5 - Pre-Operaton & Workplace Inspecton February 2019 Pre-Operation Inspection Report Be sure that the operator’s, safety and responsibilities manuals are complete, legible and in the storage container located in the platform. Be sure that all decals are legible and in place. See Decals section. Check for engine oil leaks and proper oil level. -
Page 18: Workplace InspectOn
Secton 5 - Pre-Operaton & Workplace Inspecton February 2019 Workplace Inspection Do Not Operate Unless: • You learn and practice the principles of safe machine operation contained in this operator’s manual. Avoid hazardous situations. Always perform a pre-operation inspection. 3����� Inspect the workplace�����... -
Page 19: Section 6 - Function Tests
Secton 6 - Functon Tests February 2019 Function Tests Function Tests Do Not Operate Unless: • You learn and practice the principles of safe machine operation contained in this operator’s manual. Avoid hazardous situations. Always perform a pre-operation inspection. Inspect the workplace. 4�����... - Page 20 Secton 6 - Functon Tests February 2019 Press and hold the lift function enable button. Press and hold the platform down button. • Result: The platform should lower the descent alarm should sound while the platform is lowering. Note:Be sure the area below the platform is clear of personnel and obstructions before continuing. Test the Auxiliary Lowering Activate the up function and raise the platform approximately 3 feet (1 m).
- Page 21 Secton 6 - Functon Tests February 2019 Test the Steering Note:When performing the steer and drive function test, stand in the platform facing the steer end of the machine. Press the drive function select button. The indicator light should turn on. Press and hold the function enable switch on the proportional control handle.
- Page 22 Secton 6 - Functon Tests February 2019 Fully lower the platform. Drive both wheels on one side onto an 4 in (10 cm) block. Raise the platform approximately 8 ft (2.5 m) from the ground. • Result: The platform should stop and the tilt alarm will sound at 180 beeps per minute. The platform controls LED readout should display LL.
- Page 23 Secton 6 - Functon Tests February 2019 Note:Verify that there are no fault codes shown on ground control display. Test the Oscillate System (elevated position) Press the lift function select button. The indicator light should turn on. Raise the platform approximately 10 feet (3 m) from the ground.
-
Page 24: Section 7 - Operating Instructions
Secton 7 - Operatng Instructons February 2019 Operating Instructions Operating Instructions Do Not Operate Unless: • You learn and practice the principles of safe machine operation contained in this operator’s manual. Avoid hazardous situations. Always perform a pre-operation inspection. Inspect the workplace. Always perform function tests prior to use. - Page 25 Secton 7 - Operatng Instructons February 2019 In cold conditions, 20°F (-6°C) and below, warm the engine for 5 minutes before operating to prevent hydraulic system damage. In extreme cold conditions, 0°F (-18°C) and below, machines should be equipped with optional cold start kits.
- Page 26 Secton 7 - Operatng Instructons February 2019 Use the direction arrows on the platform controls to identify the direction the machine will travel. Machine travel speed is restricted when the platform is raised. Drive speed select The following drive speeds are only allowed when the machine is stowed. In elevated drive only a restricted creep speed is allowed.
- Page 27 Secton 7 - Operatng Instructons February 2019 To Extend and Retract Platform Lift the platform extension lock handle to the horizontal position. Push the platform extension lock handle to extend the platform to the desired position. Note:Do not stand on the platform extension while trying to extend it. Lower the platform extension lock handle.
- Page 28 Secton 7 - Operatng Instructons February 2019 Closed Latch Open Latch Fully lower the platform and retract the platform extension. Remove the platform controls. Opening the latches in the corners the rails have to be folded in correct order of the numbering. How to Raise the Guardrails Follow the fold down instructions but in reverse order.
-
Page 29: Section 8 - Transport And Lifting Instructions
Secton 8 - Transport and Lftng Instructons February 2019 Transport and Lifting Instructions Transport and Lifting Instructions Observe and Obey: Common sense and planning must be applied to control the movement of the machine when lifting it with a crane or forklift. Only qualified aerial lift operators should move the machine on or off the truck. -
Page 30: SecurNg To Truck Or TraLer For TransT
Secton 8 - Transport and Lftng Instructons February 2019 Securing to Truck or Trailer for Transit Always chock the machine wheels in preparation for transport. Retract and secure the extension deck(s). Use the tie-down points on the chassis for anchoring down to the transport surface. Use a minimum of four chains or straps. - Page 31 Secton 8 - Transport and Lftng Instructons February 2019 Lifting Instructions Observe and Obey: Only qualified riggers should rig and lift the machine. Only qualified forklift operators should lift the machine with a forklift. Be sure the crane capacity, loading surfaces and straps or lines are sufficient to withstand the machine weight.
-
Page 32: Rt MachNe Decal LocatOns
Secton 9 - Decals February 2019 RT Machine Decal Locations RT Machine Decal Locations 4252 * On Material Rack 24 25 Page 29 69 Seres - Operator’s Manual... - Page 33 Secton 9 - Decals February 2019 9465 91975 91850 90732 91553 Qty - 4 Qty - 2 Qty - 4 Qty - 1 Qty - 1 3369RT (Only) 4069RT (Only) 90725 6873 93572 94857 93209 Qty - 2 Qty - 1 Qty - 2 Qty - 4 Qty - 4...
- Page 34 Decal, Hydraulic Oil 93572 Decal, Glow Plug, ANSI/CSA 9052 Decal, Main Lockout Switch 90751 Decal, Power To Platform 90719 Decal, MEC Oval 92416 Decal, Website 91973 Decal, Tie Down 94872 Decal, Warning, Sheet Material Rack 300 LBS 94868 Decal, 3369 Capacity, 9.25 in × 2.75 in (3369RT Only) 94870 Decal, 4069 Capacity, 9.25 in ×...
- Page 35 Secton 9 - Decals February 2019 ERT Machine Decal Locations 13 15 4252 *Second decal inside hood 22 23 Page 32 69 Seres - Operator’s Manual...
- Page 36 Secton 9 - Decals February 2019 3369ERT (Only) 4069ERT (Only) 91850 90732 94856 93052 Qty - 4 Qty - 1 Qty - 4 Qty - 4 91553 90725 6873 9052 Qty - 1 Qty - 2 Qty - 1 Qty - 1 90751 90719 92416...
- Page 37 Decal, Tire Replacement 6873 Decal, Hydraulic Oil 9052 Decal, Main Lockout Switch 90751 Decal, Power To Platform 90719 Decal, MEC Oval 92416 Decal, Website 91973 Decal, Tie Down 94872 Decal, Warning, Sheet Material Rack 300 LBS 94868 Decal, 3369 Capacity, 9.25 in × 2.75 in (3369ERT Only) 94870 Decal, 4069 Capacity, 9.25 in ×...
- Page 38 Service Parts Order Form Fax to 559 - 263 - 9631 Please fill out completely Date: Ordered By: Account: Your Fax No.: Ship to: Bill to: Purchase Order Number Ship VIA ** All orders MUST have a Purchase Order Number **Fed Ex shipments require Fed Ex account number Part Number Description...
- Page 39 MEC Aerial Platform Sales Corp. and is found upon inspection by MEC Aerial Platform Sales Corp. to be defective in material and/or workmanship. MEC Aerial Platform Sales Corp. shall not be liable for any consequential, incidental or contingent damages whatsoever.
- Page 40 MEC Aerial Work Platforms 1401 S. Madera Avenue, Kerman, CA 93630 USA Toll Free: 1 - 877 - 632 - 5438 Phone: 1 - 559 - 842 - 1500 Fax: 1 - 559 - 842 - 1520 info@MECawp.com www.MECawp.com...
