Chapter 3

Overview

This chapter discusses the chips and connectors of the module features in the following order:
Memory Map
Interrupt Channel Assignments
I/O Address Map
Utility 1 Interface
Serial 1 & 2 Interfaces
Parallel Interface
USB 1 & 2 Interfaces
Mouse
Keyboard
Speaker
Reset Switch
HDD Activity LED
Battery
Utility 2 Interface
Floppy Interface
IDE Signals
Video Interface
VGA
LVDS
System Fan
Power Interface
Miscellaneous
Time of Day/RTC
Oops! Jumper
Serial Console
Watchdog Timer
NOTE
ADLINK Technology, Inc. only supports the features/options tested and listed in
this manual. The main chips used in the CoreModule 740 may provide more
features or options than are listed for the CoreModule 740, but some of these
features/options are not supported on the module and will not function as
specified in the chip documentation.
The pinout tables only of non-standard headers and connectors are included in
this chapter. This chapter does not include pinout tables for standard headers and
connectors such as 44-pin IDE, PC/104, and PC/104-Plus.
CoreModule 740
Hardware
Reference Manual
15
