Appendix B
Table B-1. Utility 1 Interface Pin Signals (J1) (Continued)
35 HD Act
36 NC
37 NC
38 NC
39 NC
40 NC
Note: The shaded areas denote power or ground. NC = Not connected at the CoreModule 740.
Table B-2 lists the signals and their descriptions for the Utility 2 interface which provides a shrouded 40-pin
header with odd/even (1, 2) pin sequence. The third column in this table denotes the corresponding pins
from the J5 header on the CoreModule 740.

Table B-2. Utility 2 Interface Pin Signals (J2)

Pin # Signal
1 STB*
2 AFD*
3 PD0
4 ERR*
5 PD1
6 Init*
7 PD2
8 SLIn*
9 PD3
10 GND
11 PD4
12 GND
13 PD5
14 GND
15 PD6
16 GND
17 PD7
18 GND
19 ACK*
20 GND
38
J5-69 IDE Hard Drive Activity – Front panel HD activity signal to LEDs
J5-71 Not Connected (External SMI)
J5-73 Not Connected (RS485 Transmit/Receive Data –)
J5-75 Not Connected (RS485 Transmit/Receive Data +)
J5-77 Not Connected (External –12V input)
J5-79 Not Connected (External –5V input)
From Description
J5
Pin #
J5-2 Strobe* – Output used to strobe data into the printer. I/O pin in ECP/
EPP mode.
J5-4 Auto Feed – This is a Request signal sent to the printer to
automatically feed one line after each line is printed.
J5-6 Parallel Data 0 – These signals (0 to 7) provide the parallel port data to
the printer.
J5-8 Parallel Error – This is a Status output signal from the printer. A Low
State indicates an error condition on the printer.
J5-10 Parallel Data 1 – Refer to PD0, pin 3, for more information.
J5-12 Parallel Initialize – This signal used to Initialize printer. Output in
standard mode, I/O in ECP/EPP mode.
J5-14 Parallel Data 2 – Refer to PD0, pin 3, for more information.
J5-16 Parallel Select In – This signal used to select the printer. I/O pin in
ECP/EPP mode.
J5-18 Parallel Data 3 – Refer to PD0, pin 3, for more information.
J5-20 Ground
J5-22 Parallel Data 4 – Refer to PD0, pin 3, for more information.
J5-24 Ground
J5-26 Parallel Data 5 – Refer to PD0, pin 3, for more information.
J5-28 Ground
J5-30 Parallel Data 6 – Refer to PD0, pin 3, for more information.
J5-32 Ground
J5-34 Parallel Data 7 – Refer to PD0, pin 3, for more information.
J5-36 Ground
J5-38 Parallel Acknowledge – This is a Status output signal from the printer.
A Low State indicates it has received the data and is ready to accept
new data.
J5-40 Ground
Reference Manual
I/O Interface Board Description
CoreModule 740
