Table B-4. Auxiliary Power Pin Signals (J11) - ADLINK Technology CoreModule 740 Reference Manual

Appendix B
Table B-4 lists the signals and their descriptions for the Auxiliary Power interface which provides a right-
angle, locking, single row 4-pin header. The third column in this table denotes the corresponding pins from
the on-board J1 header.

Table B-4. Auxiliary Power Pin Signals (J11)

Pin # Signal
1 -12V (NC)
2 GND (NC)
3 -5V (NC)
4 GND (NC)
Note: The shaded areas denote power or ground. NC = Not Connected at the CoreModule 740. This
table is only for reference. The CoreModule 740 has no function for this header.
40
From On-Board Description
Connector & Pin #
J1-39 External -12 volt input (Not Connected)
NA Ground (Not Connected)
J1-40 External -5 volt input (Not Connected)
NA Ground (Not Connected)
