Figure 2-6. Header And Connector Locations (Top-Side View); Figure 2-7. Header And Connector Locations (Bottom-Side View) - ADLINK Technology CoreModule 740 Reference Manual

Chapter 2
Key:
J1 - PC/104 Plus
J2 - PC/104
J4 - Utility 2
J5 - Utility 1
J6 - Fan
J7 - Power
JP1 - See jumper table
JP2 - See jumper table
Key:
J8 - Not Populated
J9 - Not Populated
J10 - Video
J11 - Not Populated
J12 - Not Supported

Figure 2-7. Header and Connector Locations (Bottom-Side View)

10
JP2 J6
DCBA
J1

Figure 2-6. Header and Connector Locations (Top-Side View)

J11
Reference Manual
J5
J4
J10
J9
J12
J8
Product Overview
BA
JP2
CD
J2
J7
CoreModule 740
