Server Rear View

Figure
Legend
A
B
C
D
E
F
G
H
Component
Keylock
SCSI knockouts (back panel)
Keyboard and mouse ports
Parallel port
Video port
Serial ports
ac power plug
ac power out/monitor plug
CAUTION:
Both power supplies must be connected to ac
power in order for your server to operate correctly. Failure to
plug in one power supply will result in a
message on the OCP panel during server power up.
FRU Replacement
P/S Failure
5-19
