7. Install the regulators in the appropriate slots on the processor module.
Refer to "Installing a Processor and Voltage Regulator Module" later in this chapter.
8. Install the second processor module. Install the retaining bracket and secure
the captive screw located on the bracket to the chassis.
CAUTION:
corresponding slot. Failure to do so might cause faulty processor
module or server operation.
Also, the processor module has two rows of gold fingers on its
edge that plug into the main logic board slot. The processor
module must be pushed firmly in the slot to engage both rows of
gold fingers or your server might not power up on boot.
9. Replace and lock the left side panel.
NOTE:
removed.
10. Connect all external devices and restore power.
Refer to the Run the SCU section later in this chapter to complete the
installation.
Make sure you align the processor module with the
Your server will not power up with the side panel
