Troubleshooting

Server Status Messages

Component
Main logic board
voltages: +12, +5,
+3.3, and -12V
Fans 1, 2, 3, 4
Processor module
voltages
Processor failure
Processors present
4-10
Possible Failures
The voltages are outside of the power
good range.
The voltage exceeds the upper limit.
The voltage falls below the lower limit.
The primary fans (fans 1 and 3) fail.
The primary fans (fans 1 and 3) and
redundant fans (fans 2 and 4) do not
operate.
The voltages are outside of the power
good range.
The voltage exceeds the upper limit.
The voltage falls below the lower limit.
A processor failure:
Internal
Over temperature
The incorrect number of processors
are present in the server.
Result
An error message displays and a
warning beep sounds.
The server will shutdown after 5
minutes.
A warning message displays and
a warning beep sounds.
The redundant fans will activate.
The server will shutdown after 10
minutes.
A message displays and a
warning beep sounds.
A warning message displays and
a warning beep sounds.
A warning message displays and
a warning beep sounds.
An error message displays and a
warning beep sounds.
Usually caused by a fan failure
and the result is that the server
shuts down.
A message displays indicating the
number of processors are present
in the server.
continued
