Server Right-Side/Rear View - Digital Equipment DIGITAL Server 7100 1200 Service Maintenance Manual

FRU Replacement

Server Right-Side/Rear View

Figure Orderable
Legend Spare Part
1 30-43120-01
2 12-41768-03
3 17-04143-02
4 54-23384-02
5 17-04143-07
6 30-48985-01
7 70-31894-01
8 70-31928-01
9 70-31890-01
10 70-31909-01
70-31909-02
11 70-31919-01
12 12-37977-04
13 74-48303-01
5-6
Exchangeable Description
Spare Part
Power supply (2)
SCSI terminator 68-position single-ended
68-pin SCSI cable assembly (jumper cable)
Hot-swap backplane module
SCSI repeater module cable
SCSI repeater module
Wire assembly (12 wires)
System power wire assembly
Wire assembly (three wires)
Micro switch cable assembly (right)
Micro switch cable assembly (left)
Door lock assembly
Rear keylock assembly
I/O expansion board cover bracket
