CPU INSTALLATION CARD
ER–PD02U–IN. A01
Use this card as a quick reference to install the CPU
module in DIGITAL Server 5300 and DIGITAL Server
7300/7300R systems.
WARNING: CPU modules and memory modules have
parts that operate at high temperatures. Wait 2 minutes
after power is removed before touching any module.
CAUTION: Wear an antistatic wrist strap when working
on this system.
Overview
•
Expose the system board or drawer in the pedestal or
cabinet.
•
•
DIGITAL Server 5300
Expose the System Board
NOTE: Before removing the CPU module, you must
remove the memory card adjacent to it. Refer to the
DIGITAL Server 5300 User's Guide for memory card
removal procedures.
1. Shut down the operating system and power down the
system.
2. Remove the top cover and left side panel as shown in
the following illustration.
© Digital Equipment Corporation 1997.
All rights reserved.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Digital Equipment 5300
Summary of Contents for Digital Equipment 5300
- Page 1 CPU INSTALLATION CARD ER–PD02U–IN. A01 Use this card as a quick reference to install the CPU module in DIGITAL Server 5300 and DIGITAL Server 7300/7300R systems. WARNING: CPU modules and memory modules have parts that operate at high temperatures. Wait 2 minutes after power is removed before touching any module.
- Page 2 Top Cover Release Latch IP00205 Install the CPU Module 1. Unscrew the module handle that secures the outer edge of the CPU module (two retainer screws). 2. Release the card by extending the handle clip on each end outward. 3. Holding the outer edge of the card, gently pull it out of the slot.
- Page 3 IP00215 Verify the Installation 1. Start AlphaBIOS Setup, select Display System Configuration, and press Enter. 2. Using the arrow keys, select MC Bus Configuration to display the status of the new module. DIGITAL Server 7300/7300R Expose the System Drawer in the Pedestal 1.
- Page 4 PK-0752-96 3. Remove the top cover from the pedestal. Remove the two Phillips head retaining screws midway up each side of the pedestal, tilt the cover up, and lift it away from the frame. PK-0753-96...
- Page 5 Expose the System Drawer in the H9A10–EN/EP Cabinet WARNING: Only DIGITAL Customer Service representatives or customer maintenance personnel who are familiar with computer hardware should slide system drawers out of the cabinet. Personnel should be experienced and trained in installing computers and related equipment.
- Page 6 Install the CPU Module 1. Remove the cover from the system card cage section of the system drawer. Remove the two Phillips head screws and slide the cover off the drawer. PK-0705AR-96 2. Insert the new CPU module: Determine the slot on the system motherboard for the new module.
- Page 7 DIGITAL Server 7300 Mother Board CPU 3 CPU 2 CPU 1 CPU 0 ML014253 b. The module handle has a lever at each end. Insert the module in the slot and push down on both levers at the same time. PK-0718R-96...
- Page 8 Verify the Installation 1. Replace the cover on the system bus card cage. Power up the system with the HALT button in the depressed position and verify that power-up diagnostics pass. 2. From the SRM console, issue the command >>>test CPUn where n is 0 ,1,2,3, o r *.
