SCU Features

System - DIGITAL Server 7100

Menu Fields
System processor
type
System processor
clock
System base
memory
System extended
memory
System extended
memory mode
System
information
System language
(1)
Factory default setting
3-2
Settings
Not user selectable
Not user selectable
Not user selectable
[memory amount], AT-bus
(1)
space disabled
[memory amount], AT-bus
space enabled at F00000h,
1M
[memory amount], AT-bus
space enabled at E00000h,
2M
[memory amount], AT-bus
space enabled at C00000h,
4M
(1)
Compatibility
Non-compatibility
Not user selectable
Not user selectable
Comments
Displays the type of the processor that is
resident on the main logic board.
Displays the clock of the processor that is
resident on the main logic board.
Displays the amount of base (conventional)
memory each time the server boots.
Displays the amount of extended memory
each time the server boots.
You can select disabling or enabling one of
three memory ranges that could be used by
expansion boards.
Selects the means for supporting extended
memory above 64 MB. Select
[Compatibility] for using conventional
service in BIOS.
Select [Non-Compatibility] for memory
support above 64 MB when using Windows
NT v3.1 or above.
Displays the version of the server BIOS.
Also, the resources occupied by the server
BIOS can be viewed via this selection.
English only.
