Integrated Peripherals Group - Digital Equipment DIGITAL Server 7100 1200 Service Maintenance Manual

SCU Features

Integrated Peripherals Group

Menu Fields
Video type
Monitor type
Mouse port
Parallel port
Serial port 1
Serial port 2
(1)
Factory default setting
3-6
Settings
(1)
VGA or EGA
CGA 80 columns
Monochrome
(1)
Color
Monochrome
Disabled
(1)
Enabled
Disabled
Compatible mode
(1)
Bi-Directional Mode
EPP 1.7 mode
EPP 1.9 mode
ECP mode
Disabled
Enable at: 3F8h-3FFh (IRQ4)
Enable at: 2F8h-2FFh (IRQ3)
Enable at: 3E8h-3Efh (IRQ4)
Enable at: 2E8h-2Efh (IRQ3)
Disabled
Enable at: 3F8h-3FFh (IRQ4)
Enable at: 2F8h-2FFh (IRQ3)
Enable at: 3E8h-3Efh (IRQ4)
Enable at: 2E8h-2Efh (IRQ3)
Comments
Sets the video controller type.
Sets the type of monitor connected
to the server: Color or Monochrome.
Enables or disables the onboard
PS/2 style mouse port.
Selects the Enhanced Parallel Port
(EPP) mode.
Selects the standard printer
connection.
Selects the PS/2 compatible mode to
receive data.
Selecting EPP 1.7 or EPP 1.9 is
based on what EPP version your
printer supports. If you are not sure
what version your printer supports,
use the default setting.
Sets the Extended Capabilities Port
(ECP) mode.
Enables or disables onboard serial
(1)
port 1 at the specified address and
IRQ.
Enables or disables onboard serial
port 2 at the specified address and
(1)
IRQ.
