Troubleshooting

VRM Voltage Range

VRM
Voltage
2.1 V
2.2 V
2.3 V
2.4 V
2.5 V
2.6 V
2.7 V
2.8 V
2.9 V
3.0 V
3.1 V
3.2 V
3.3 V
3.4 V
3.5 V

Processor Temperature Warning Levels

Warning Level
>85 °C
4-18
Power Good
Range
+1.95 to 2.25 V
+2.04 to 2.35 V
+2.14 to 2.46 V
+2.23 to 2.46 V
+2.32 to 2.68 V
+2.42 to 2.78 V
+2.51 to 2.89 V
+2.60 to 3.00 V
+2.70 to 3.10 V
+2.79 to 3.21 V
+2.88 to 3.32 V
+2.97 to 3.42 V
+3.07 to 3.53 V
+3.16 to 3.64 V
+3.25 to 3.75 V
Upper Limit
>90 °C
Lower
Limit
<+1.89 V
<+1.98 V
<+2.07 V
<+2.16 V
<+2.25 V
<+2.34 V
<+2.43 V
<+2.52 V
<+2.61 V
<+2.70 V
<+2.79 V
<+2.88 V
<+2.97 V
<+3.06 V
<+3.15 V
Backup Fan Activated
>82 °C
Upper
Limit
>+2.31 V
>+2.42 V
>+2.53 V
>+2.64 V
>+2.75 V
>+2.86 V
>+2.97 V
>+3.08 V
>+3.19 V
>+3.30 V
>+3.41 V
>+3.52 V
>+3.63 V
>+3.74 V
>+3.84 V
