Server Processor Voltage and Temperature Ranges

The following tables list the processor and Voltage Regulator Module (VRM)
operating voltage and temperature ranges.

Processor Voltage Range

Nominal Nominal
Tolerance
+12 -4 to + 5
+5 -2 to + 5
+3.43 -1 to + 1
-12 -10 to + 10
VGTL -10 to + 10
Normal Voltage
Range
+11.1 to +13.0 V
+4.80 to +5.35 V
+3.32 to +3.54 V
-13.7 to -10.3 V
+1.32 to +1.68 V
Server Error Server Shutdown
Occurs Occurs
<+9.0 V >+13.8 V
<+4.3 V >+5.80 V
<+3.0 V >+3.80 V
>-9.0 V <-14.2 V
<+1.10 V >+1.80 V
Troubleshooting
4-17
