Eurotech Apollo User Manual page 63

Field
Floppy disk
controller
IDE Controller
Local Bus IDE
adapter
AC97 Audio
Issue G
Explanation
Used to configure the floppy disk controller. The options available
are:
• Disabled
. The port is not configured at all - it is turned off.
• Enabled
. You are going to configure the port (by completing
the following fields).
• Auto
. The port is configured automatically by the BIOS or the
operating system.
OS Controlled is displayed if configuration of the port is
controlled by the operating system.
Choose whether to enable or disable the IDE controller. This
should be Enabled for CompactFlash
IDE is not being used.
Choose which IDE adapter (or adapters) is to be enabled. You
can select Primary channel, the Secondary channel, Both or
neither (choose Disabled).
The APOLLO supports only a single IDE hard drive connection,
which is the primary IDE adapter. However, the secondary IDE
adapter must be enabled for the CompactFlash boot functionality
to operate correctly. This means that, for correct operation of the
CompactFlash boot feature, you should ensure that the
secondary IDE adapter is enabled (i.e. that you select either
Secondary or Both).
Choose whether to enable or disable the onboard AC97 audio
device.
PhoenixBIOS features and setup
®
boot, even if the onboard
63
